BG-UM44-100M-KIT
4X4 4K 18Gbps UHD HDMI/HDBaseT/Audio Matrix Switcher with
2-Way IR/ARC/Ethernet/IP and RS-232 Control
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BG-UM44-100M-KIT and is the answer not in the manual?

Questions and answers

Related Manuals for BZB Gear BG-UM44-100M-KIT

Summary of Contents for BZB Gear BG-UM44-100M-KIT

  • Page 1 BG-UM44-100M-KIT 4X4 4K 18Gbps UHD HDMI/HDBaseT/Audio Matrix Switcher with 2-Way IR/ARC/Ethernet/IP and RS-232 Control User Manual...

  • Page 2: Table Of Contents

    BZBGEAR BG-UM44-100M-KIT PRODUCT MANUAL TABLE OF CONTENTS Statement Safety Precaution Introduction Features Packing List Specifications Operation Controls and Functions IR Remote IR Control System IR Cable Pin Assignment EDID Management Matrix Audio and RS-232 Introduction Web GUI User Guide RS-232 Control Command...

  • Page 3: Statement

    BZBGEAR BG-UM44-100M-KIT PRODUCT MANUAL Statement Please read these instructions carefully before connecting, operating, or configuring this product. Please save this manual for future reference. Safety Precaution ● To prevent damaging this product, avoid heavy pressure, strong vibration, or immersion during transportation, storage, and installation.

  • Page 4: Introduction

    PRODUCT MANUAL Introduction The BG-UM44-100M-KIT is a 4K UHD 4X4 HDMI HDBaseT matrix switch that can connect four HDMI sources to eight displays. This device features four HDMI outputs mirrored to four simultaneous HDBaseT outputs. The HDBaseT outputs can extend a 4K@60Hz 4:4:4 video signal at distances up to 328 feet (100 meters) over a single Cat5e/6/7 cable.

  • Page 5: Packing List

    BZBGEAR BG-UM44-100M-KIT PRODUCT MANUAL Packing List ● 1x 4x4 HDMI and HDBaseT Matrix ● 8x 3-pin Phoenix Connector Switch ● 5x IR Blaster cable (1.5 meters) ● 4x HDBaseT Receiver ● 6x 20~60KHz IR Receiver cable (1.5 ● 1x Matrix IR Remote meters) ●...

  • Page 6: Operation Controls And Functions

    BZBGEAR BG-UM44-100M-KIT PRODUCT MANUAL Mechanical Housing Metal Enclosure Color Black TX: 440mm (W)×274mm (D)×45mm (H) Dimensions RX: 163mm (W)×90.3mm (D)×18mm (H) Weight TX: 3977g, RX: 392g Power Supply AC 100 - 240V 50/60Hz Power Consumption 70W (Max) Operating Temperature 0°C ~ 40°C / 32°F ~ 104°F Storage Temperature -20°C ~ 60°C / -4°F ~ 140°F...
  • Page 7 BZBGEAR BG-UM44-100M-KIT PRODUCT MANUAL Rear Panel Name Function Description If the IR receiver window of the unit is blocked or the unit is installed in a closed area out of IR EXT infrared line of sight, the IR receiver cable can be inserted to the “IR EXT” port to receive the IR remote signal.
  • Page 8 BZBGEAR BG-UM44-100M-KIT PRODUCT MANUAL HDBaseT Receiver Panel Function Description Name POWER LED Power LED indicator, LED will illuminate when the device is connected to a power supply. SERVICE port Firmware update port P. lug the DC 24V/1A power cord into this port and connect the adapter to AC wall outlet.

  • Page 9: Ir Remote

    BZBGEAR BG-UM44-100M-KIT PRODUCT MANUAL IR Remote 1. Power on or Standby: Power on the Matrix or set it to standby mode. 2. Output 1: Press 1\2\3\4 button to select input source to HDMI OUTPUT 1. 3. Output 2: Press 1\2\3\4 button to select input source to HDMI OUTPUT 2.

  • Page 10: Ir Control System

    PRODUCT MANUAL IR Control System The BG-UM44-100M-KIT is not only a matrix switch but also an extender that supports bi-directional IR control. When the matrix is connected to a HDBaseT receiver through a Cat 5e/6/7 cable, you can control the remote display device (HDBaseT) or input source device (matrix) through an IR signal transmission.
  • Page 11 BZBGEAR BG-UM44-100M-KIT PRODUCT MANUAL Figure 1: IR connection diagram (Matrix end) At HDBaseT Receiver (Remote end): IR signal follows video switch/change. For example, the HDMI output signal on the HDBaseT Receiver 1 is from the HDMI INPUT 2 port, so the IR input signal of the HDBaseT Receiver 1 will emit to IR OUT 2 of the matrix.

  • Page 12: Edid Management

    IR Cables EDID Management The BG-UM44-100M-KIT has 21 factory defined EDID settings, 2 user-defined EDID modes and 8 copy EDID modes. You can select defined EDID mode or copy EDID mode to input port through on-panel button, ASCII control or Web GUI.
  • Page 13 BZBGEAR BG-UM44-100M-KIT PRODUCT MANUAL The defined EDID setting list of the product is shown as below: EDID Mode EDID Description 1080p, Stereo Audio 2.0 1080p, Dolby/DTS 5.1 1080p, HD Audio 7.1 1080i, Stereo Audio 2.0 1080i, Dolby/DTS 5.1 1080i, HD Audio 7.1 3D, Stereo Audio 2.0...

  • Page 14: Matrix Audio And Rs-232 Introduction

    BZBGEAR BG-UM44-100M-KIT PRODUCT MANUAL Matrix Audio and RS-232 Introduction The matrix supports coaxial and analog audio output. The audio signal follows HDBaseT and HDMI output port. It supports one-to-one transmission. For example, the OUTPUT 1 port audio signal follows HDBaseT and HDMI 1 port, the OUTPUT 2 port audio signal follows HDBaseT and HDMI 2 port etc.

  • Page 15: Web Gui User Guide

    BZBGEAR BG-UM44-100M-KIT PRODUCT MANUAL Web GUI User Guide The matrix can be controlled through a web interface and operation is shown below. Step 1: Get the current IP Address. The default IP address is 192.168.1.100. You can get the current matrix IP address in two ways: 1.
  • Page 16 BZBGEAR BG-UM44-100M-KIT PRODUCT MANUAL Click on the bubble for “Use the following IP address” In the IP address field enter a non-conflicting IP address on the same subnet as the camera. If there is another device with the same IP address you will not be able to connect.
  • Page 17 BZBGEAR BG-UM44-100M-KIT PRODUCT MANUAL After entering the IP address of the unit in the browser the Login page will appear as shown below: Select the Username from the list and enter the password. The default passwords are: Username User Admin...
  • Page 18 BZBGEAR BG-UM44-100M-KIT PRODUCT MANUAL Video Page 1. Output: The current device’s OUTPUT port. 2. Input: You can click the drop-down menu to select a signal source for the corresponding OUTPUT port . 3. Presets Name: You can name the current scene with a maximum length of 12 characters.
  • Page 19 BZBGEAR BG-UM44-100M-KIT PRODUCT MANUAL Audio-HDMI Page 1. HDMI: Audio channel of the current Output. 2. Audio Source: The input source of the current audio channel. You can switch the input source by clicking the corresponding drop-down box to select the desired input source.
  • Page 20 BZBGEAR BG-UM44-100M-KIT PRODUCT MANUAL Input Page 1. Inputs: Input channel of the device. 2. Active: It indicates whether the channel is connected to a signal source. 3. Name: The input channel’s name. You can modify it by entering the corresponding name (max length: 12 characters) in the input box (Chinese name is unsupported).
  • Page 21 BZBGEAR BG-UM44-100M-KIT PRODUCT MANUAL Make sure to select the correct file, then you can check the name of the selected file. Select “User 1” or “User 2”, then click “Upload”. After successful setting, it will prompt as follows: Download the EDID File for the Corresponding Input Channel Click the drop-down box of “Select EDID File”...
  • Page 22 BZBGEAR BG-UM44-100M-KIT PRODUCT MANUAL CEC Page 1. Input Control: You can control the operation of each input source by pressing the icons on the page. 2. Output Control: You can control the operation of each display, such as power on/off, volume +/-, active source switching.
  • Page 23 BZBGEAR BG-UM44-100M-KIT PRODUCT MANUAL Set the Default Network Click “Set Network Defaults” button, there will be a prompt, as shown in the following figure: Click “OK” to search the IP Address again, as shown in the following figure: After searching is completed, it will switch to the login page, the default network setting is completed.
  • Page 24 BZBGEAR BG-UM44-100M-KIT PRODUCT MANUAL Note: Input rules for changing passwords: 1. The password can’t be empty. 2. The new password can’t be the same as the old password. 3. The new password and confirm password must be the same. Modify Network Setting Modify the Mode/IP Address/Gateway/Subnet Mask/Telnet Port as required, click “Save”...
  • Page 25 BZBGEAR BG-UM44-100M-KIT PRODUCT MANUAL System Page 1. Panel Lock: Click “Panel Lock” to lock/unlock panel buttons. “On” indicates that panel buttons are unavailable; “Off” indicates panel buttons are available. 2. Beep: Click “Beep” to turn on/off the beep. 3. LCD: You can turn on/off the LCD and set the turn-on time (15s/30s/60s).

  • Page 26: Rs-232 Control Command

    BZBGEAR BG-UM44-100M-KIT PRODUCT MANUAL RS-232 Control Command The product also supports RS-232 control. You need a serial cable with RS-232 male head and DB9 transfer USB male head. The RS-232 head of the serial cable is connected to the RS-232 control port with DB 9 at the rear of the Matrix, and the USB head of the serial cable is connected to a PC.
  • Page 27 BZBGEAR BG-UM44-100M-KIT PRODUCT MANUAL ASCII Command Function Description Example Feedback Default Setting s beep z! Enable/Disable buzzer function, s beep 1! beep on beep on z=0~1(z=0 beep off, z=1 beep on) beep off r beep! Get buzzer state r beep! beep on / beep off...
  • Page 28 BZBGEAR BG-UM44-100M-KIT PRODUCT MANUAL ASCII Command Function Description Example Feedback Default Setting 2=1080p,Dolby/DTS 5.1 Stereo Audio 3=1080p,HD Audio 7.1 2.0 IN3: 1080p, 4=1080i,Stereo Audio 2.0 Stereo Audio 5=1080i,Dolby/DTS 5.1 2.0 IN4: 1080p, 6=1080i,HD Audio 7.1 Stereo Audio 7=3D,Stereo Audio 2.0 8=3D,Dolby/DTS 5.1...
  • Page 29 BZBGEAR BG-UM44-100M-KIT PRODUCT MANUAL ASCII Command Function Description Example Feedback Default Setting s coax_analog Set coaxial output audio y=0~4 s coax_analog Coaxial_Analog output 1 audio: Coaxial_Analog out y audio from (0=all),z=1~1 out 1 audio from HDMI input 1 all outputs...
  • Page 30 BZBGEAR BG-UM44-100M-KIT PRODUCT MANUAL ASCII Command Function Description Example Feedback Default Setting s cec in x next! set input x next by CEC, x=0~4(0=all s cec in 1 next! input 1 next operation input) s cec hdmi out y set hdmi output y power on by CEC,...

  • Page 31: Application Example

    BZBGEAR BG-UM44-100M-KIT PRODUCT MANUAL ASCII Command Function Description Example Feedback Default Setting s telnet port x! Set network telnet port (x=1~65535) s telnet port 23! Set Telnet port:23 Set telnet port:23 r telnet port! Get network telnet port r telnet port!

  • Page 32: Tech Support

    BZBGEAR BG-UM44-100M-KIT PRODUCT MANUAL Tech Support Have technical questions? We may have answered them already! Please visit BZBGEAR’s support page (bzbgear.com/support) for helpful information and tips regarding our products. Here you will find our Knowledge Base (bzbgear.com/knowledge-base) with detailed tutorials, quick start guides, and step-by-step troubleshooting instructions.
