Warning
Do not disassemble or modify this product. Such actions can not only damage or destroy
the product but also will void the warranty.
Disassemble/modify
Do not perform installation of this product immediately after the engine has been
switched off. The engine and exhaust system are extremely hot at this time and can cause
burns if touched.
Please keep children and infants away from the installation area. Children may swallow
small parts or be injured in other ways.
Do not install this product in the area where safety equipment such as air bags are
mounted. This may cause more injuries in the event of accident.
Carefully consider the installation location and driver's operation of the product before
installation. Do not install the product where it interrupts driving and the safety devices of
vehicle such as air bags. Be sure not to install the unit where it could fall. Improper
installation or operation could cause the product to fall and damage the vehicle or cause
serious danger by impeding driving.
Ensure that the wiring of this product does not have an adverse impact on the other
wiring of the vehicle. Incorrect wiring may destroy your ECU, ignition system and other
engine management devices. When tapping engine rev or speed signal from the ECU,
please make sure to follow the procedure as below:
1. Make sure that you have connected the power supply wire of the advance control unit.
2. Confirm that the DC Source LED of the advance control unit is lighted with ignition on.
3. Remove negative terminal connector from battery and tap engine rev or speed signal
from ECU.
Caution
Do not drop any of the components of this product. It may result in damage to the
product.
Do not apply excessive force on switches/terminals. It may result in damage to the
product.
Do not use wires other than the provided wires.
