Illumination

9.4.3.
■ADVANCE RS/CR gauges
The illumination of RS/CR gauges are turned on/off being interlocked with the vehicle
illumination switch. By pressing 【RIGHT button】 several times during Real mode, the
gauge illumination is turned off even if the vehicle illumination is on. (Illumination cancel)
■ADVANCE A1/BF gauges
The brightness of gauge illumination can be adjusted by pressing 【RIGHT button】 during
Real mode. Five levels of brightness are provided for daytime and nighttime separately. The
brightness level is shifted from daytime level to nighttime level being interlocked with the
vehicle illumination switch.
By pressing 【RIGHT button】 several times during Real mode, the gauge illumination is
shifted to the maximum brightness level even if the vehicle illumination is on. (Illumination
cancel)
■ADVANCE FD/ZD
A dimming sensor is equipped with FD/ZD. For brightness adjustment, either AUTO or
MANUAL control can be selected. If AUTO is selected, the brightness of the display is
adjusted automatically depending on the outside light.
By connecting displays to the control unit and using AUTO control, the illuminations of the
switch unit and connected gauges of ADVANCE series are controlled automatically.
Switch unit/ADVANCE RS/CR: Turned ON/OFF automatically
ADVANCE A1/BF: Adjusted automatically
