Offset adjustment of Turbo (2.0 and 1.2) and In-Mani Press

9.7.4.
The needle pointer of turbo should indicate 0kPa when the ignition is on. But in rare cases
the needle pointer is not indicating exactly 0kPa. If this happens, it is possible to adjust.
1. Set the slide switch to 【LOWER】.
2. Press 【LEFT button】. The gauge shifts to the setup mode.
3. Select the gauge to set by pressing 【LEFT button】.
4. Press 【LEFT button】 long. The adjustment is confirmed by a short beep sound.
5. After adjustment is done, return the slide switch to 【UPPER】.
This function is not available for Turbo 3.0 gauge.
