tachometer response.
3. Press 【LEFT button】 long during the setting mode for the number of cylinders. The
gauge shifts to the setting mode for tachometer response. The peak and warning LEDs
in the gauge are lighted up.
4. Press 【RIGHT button】 to change the level in the following order: 1 → 2 → 3.
Press 【MIDDLE button】 to change the level in the following order: 3 → 2 → 1.
1000rpm, 2000rpm and 3000rpm indicate level 1, level 2 and level 3 respectively.
5. After completion of setting, return the slide switch to 【UPPER】.

9.7. Setup mode

Slide switch position : 【LOWER】
By setting warning values, the warning LEDs on the gauges light on when the gauges reach
or exceed the values. In case of oil pressure and fuel pressure, the warning LED lights on
when the gauge reaches or falls below the value set for warning. If displays are installed,
the warning setting is displayed on the screen. Warning values for gauges and displays are
set at the same time.
In addition, the illumination colors of RS/CR gauges can be selected from 2 colors in this
mode. Illumination color of A1/BF and displays cannot be changed.
■Warning factory default settings
Gauge default setting
Turbo3.0
Turbo1.2/2.0
In-Mani Press
Tachometer
Oil Press
Fuel Press
Oil Temp
Water Temp
Exhaust Temp
Depending on vehicle type and/or condition, vehicle may be damaged even if the values are
under the warning factory default setting value (over the warning factory default setting
value in case of oil pressure and fuel pressure). Be sure to consult store professional to set
warning values.
ADVANCE Control Unit SE Manual
Unit Minimum Maximum
166.7 kPa
100 kPa
10 kPa
7000 rpm
120 kPa
150 kPa
125 ℃
105 ℃
850 ℃
Setting range
-100 300
-100 200
-100 300
300 11000
0 1000
0 600
0 150
0 150
0 1100
32
Lighting condition
set value and above
set value and above
set value and above
set value and above
set value and below
set value and below
set value and above
set value and above
set value and above
