9.3. Opening mode / Ending mode

When the ignition is turned on, gauges and ZDs perform opening mode. When the ignition
is turned off, gauge and ZDs perform ending mode and then the power supplies of the
control unit, gauges, and ZDs are shut off.
Confirmation
Depending on vehicles, the ignition is not turned off immediately after the key is turned
off. In this case, ending mode doesn't start until the ignition is turned off.
If the ignition is turned off during setting, the setting data will not be saved.
If the power wire is wired correctly, the DC Source LED lights in white from the beginning
of the opening mode. If it stays off or is blinking, turn the ignition off and check the wiring.
⇒8. How to install <for customer and installation personnel>.

Change of Opening mode / Ending mode

9.3.1.
Opening and ending modes can be selected from "A" type (simple) and "B" type (special)
by sliding the dip switch 2 on the control unit.
Both types consists of lighting/blinking of peak & warning LED, the dial illumination, and
sequential indicators of displays, besides pointer movement and digital display. Try both
types!
Confirmation
Please slide the switch when the ignition is off.
The modes for all the connected gauges and displays are changed at the same time.
It might be hard to see the dial illumination depending on outside light level.
