7. Connect the sensor and the sensor wire. Then connect to the control unit.
8. To confirm the wiring and connection, connect gauges and displays to the control unit
temporarily by using meter wires. Do not fix the gauge at this stage.
Do not remove the convex connector if you use only one METER OUTPUT connector to
protect against short-circuit between two terminals.
9. Connect the negative battery terminal.
10. Confirm that the DC SOURCE LED is on when the ignition is on. If the power supply
wire is wired correctly, the DC SOURCE LED of the control unit lights in white. And also
look see that RS/CR gauges' illumination lights up or BF/A1 gauges' illumination darkens
or display's switch illumination lights up when the illumination switch of the vehicle is
on.
●The DC SOURCE LED is not on: The power supply is not taken.
→Turn the ignition off, then please confirm the wiring of the power supply wire.
●The warning LED of gauge is blinking or the warning LED and peak LED are blinking at
the same time: disconnection, short circuit, or communication error is occurred.
→Turn the ignition off, then please confirm the wiring of the sensor and the sensor wire.
⇒9.4.2 Error displays of wire disconnection, short circuit, and serial error
Warning
If the wiring defects are not found, it is probable that there is a defect in the product.
Please detach the product immediately and ask for inspection. It may damage the
vehicle.
⇒11. Maintenance / Inspection / Warranty / After-sales service
<for customer and installation personnel>
11. Turn the ignition OFF.
12. Disconnect the meter wire from the gauge, and attach the gauge by using mounting
bracket. Confirm it is installed firmly, then connect the meter wire again.
⇒Refer to Refer to each gauge operation manual
13. Connect the switch unit to the control unit and fix the switch unit with double sided
tape. Before attaching it, make sure the surface is clean.
⇒7. Part names / dimensions
<for customer and installation personnel>
14. Set 2 dip switches of the control unit.
