□Check that the sensor and wires are not interfering with the engine operation.
□Ensure that the gauge and wires are tightly attached, so they don't come loose and
hinder driving.
□Check that all wires disconnected from the vehicle during installation have been properly
reattached.
Warning
After installation, check that no materials or tools remain in the driver's seat or the
engine compartment. If there are tools left at the feet of the driver's seat, this may cause a
driver to lose control of brake because of tools or materials caught under the brake pedal. If
there are tools in the engine compartment, the engine may break.
□Ensure that the negative battery terminal is tightly attached. Close the hood properly.
This concludes the installation process.
Confirmation
The protection film is attached to ADVANCE Control Unit and the switch unit. Please
peel off before using. It may be sticked by aging of the glue.
