Jaga STRADA HYBRID BMS MODUS Installation And Operation Manual page 30

08
10
12
30
OPTION
Red
Brown
DBH Therm.
Black Blue
Option - 24 VDC
JAGA N.V. | DBH SET - BMS | MANUEL | 2021.08.23 | V.01
09
Connect the device hydraulically.
With cooling : This device is not equipped with
dew point control. This must be installed in the
most critical place by the installer! Condensing
cooling due to a dew point control malfunction
may damage the device and its surroundings. !
Jaga is not responsible for this.
11
±2 cm
13
