3. OPERATION
Only in combination with a suitable heat
pump and control valve for heating and
cooling
2⁰C
The device automatically enters cooling mode when the water temperature is 2°C/4°F below the
room temperature. If the differential between room and water temperature is less than 1
device will automatically switch to standby.
The unit starts when the water temperature is < 24°C and the control signal is 1-10V.
The unit is in standby. The unit automatically starts a new cycle if the preset temperature is rea-
ched.
The device automatically enters heating mode when the water
°
temperature is 4 C/7°F above the room temperature. If the
differential between room and water temperature is less than
°
1 C/2°F higher than the room temperature, the device will
automatically switch to standby.
The unit starts if the water temperature is > 28°C/82 ̊ F and the
control signal is 1-10V.
Fan speed in function of the incoming control signal.
JAGA N.V. | DBH SET - BMS | MANUEL | 2021.08.23 | V.01
15
1⁰C
Standby mode
1⁰C
° C/2°F, the
Max
Min
0 1
curve : Speed versus 0-10V control signal
