Forma ULT Freezer
Model 700 Series Chest Freezer
Manual Number 7010708 Rev. 10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 700 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Thermo Scientific 700 Series

Summary of Contents for Thermo Scientific 700 Series

  • Page 1 Forma ULT Freezer Model 700 Series Chest Freezer Manual Number 7010708 Rev. 10...
  • Page 2 Preface Models Covered Models Capacity Voltage 12.7 12.7 Packing List Part Number Description Quantity 34040 Key Ring 213F 380520 Neoprene Cap 510016 1/4-20 x 5-1/2” Bolt 402058 Vacu-Key 195763 Retaining Clip 370563 Remote Alarm Connector MANUAL NUMBER 7010708 23939 5/29/07 Added note - adjust LN tank pressure relief valve to 30 PSI maximum blow-off 24100...
  • Page 3 Preface Important Read this instruction manual. Failure to read, understand and follow the instructions in this manual may result in damage to the unit, injury to operating personnel, and poor equipment performance. ▲ Caution All internal adjustments and maintenance must be performed by qualified service personnel. ▲...
  • Page 4 Preface Important operating and/or maintenance instructions. Read the accompanying text carefully. Potential electrical hazards. Only qualified persons should perform procedures associated with this symbol. Equipment being maintained or serviced must be turned off and locked off to prevent possible injury. Hot surface(s) present which may cause burns to unprotected skin, or to materials which may be damaged by elevated temperatures.
  • Page 5 Preface Do You Need Information or Assistance on Thermo Fisher Scientific Products? If you do, please contact us 8:00 a.m. to 6:00 p.m. (Eastern Time) at: 1-740-373-4763 Direct 1-888-213-1790 Toll Free, U.S. and Canada 1-740-373-4189 http://www.thermo.com/forma Internet Worldwide Web Home Page services.controlenv@thermo.com Service E-Mail Address Sales Support...

  • Page 6: Table Of Contents

    Table of Contents Section 1 Installation and Start-up ........1 - 1 Freezer Components .
  • Page 7 Table of Contents Section 5 Factory Options ..........5 - 1 BUS (Back Up System) .

  • Page 8: Installation And Start-Up

    Installation and Start-up Section 1 Freezer Components Figures 1-1 and 1-2 show the front view of the freezer and indicate the following freezer components: • Control Panel - keypad, displays and indicators • BUS (Optional Back Up System) panel • Optional temperature recorder (7 day, one pen) or datalogger •...
  • Page 9 Section 1 Installation and Start-up Figures 1-3 and 1-4 display the rear view of the freezer and indicate the following freezer components: • Remote alarm contacts. • Power inlet for power cord connection. • Optional BUS connections for probe and solenoid. •...
  • Page 10 Section 1 Installation and Start-up The probe cover - houses the control, optional recorder, datalogger, 1535 alarm, or BUS probes. Figure 1-5. Probe Cover Figures 1-6, 1-7, and 1-8 indicate the following components: • Freezer filter location. • Battery power switch (freezer and BUS). •...
  • Page 11 Section 1 Installation and Start-up Figure 1-7. Freezer Left Side - Sidecar panel removed Thermocouple remove filter Receptacle a a a a a a a a Battery a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a a...
  • Page 12 Section 1 Installation and Start-up Control Panel Keys, 1. Temperature Display - Displays temperature in degrees Celsius. Display, Indicators 2. Mode Select Switch - Used to select Run, Set Temperature, Set High Alarm, Set Low Alarm, Calibrate, Backup. 3. Alarm Indicator - Light pulses on/off during an alarm condition of the cabinet.

  • Page 13: Operation Of The Keypad

    Section 1 Installation and Start-up Operation of Keypad The 700 Series freezer has five basic modes which allow freezer setup and operation. Press the Mode key to scroll through the mode selections. Up Arrow: Increases or toggles the parameter value.

  • Page 14: Install Wall Bumpers

    Section 1 Installation and Start-up Install Wall Bumpers The parts bag, located inside the cabinet, contains the following parts. Quantity Stock # Description Purpose 510016 1/4-20 x 5-1/2” Bolt Wall Bumper 380520 Neoprene Cap Cap Protector Install the bolts into the pre-tapped holes on the back of the freezer. Install a neoprene cap on each bolt.

  • Page 15: Attach Power Cord

    Section 1 Installation and Start-up Attach Power Cord Insert the power cord into the power inlet module. Place the retaining bracket (P/N 195763) over the connector. Tighten retaining screws to secure. Figure 1-11. Power cord retaining bracket Connect Unit to Electrical Note See the serial tag on the side of the unit for electrical specifications or refer to the electrical schematics in this manual.

  • Page 16: Freezer Start-Up

    Section 1 Installation and Start-up Freezer Start-Up With the freezer properly installed and connected to power, system set points can be entered. The following set points can be entered in Settings mode: Control temperature, high temperature alarm set point, low temperature alarm set point, and (optional) BUS set point.

  • Page 17: Set High Temperature Alarm

    Section 1 Installation and Start-up Set High Temperature The high temperature alarm will activate an audible/visual warning when the freezer chamber temperature has reached or exceeded the high Alarm temperature alarm set point. To set the high temperature alarm set point: 1.

  • Page 18: Run Mode

    Section 1 Installation and Start-up Run Mode The Run mode is the default mode for the freezer. Run mode displays the cabinet temperature on the temperature display under normal operating conditions. In addition, Run mode allows the high stage heat exchange temperature to be displayed.

  • Page 20: Calibrate

    Calibrate Section 2 Calibrate Mode Once the freezer has stabilized, the control probe may need to be calibrated. Calibration frequency is dependent on use, ambient conditions and accuracy required. A good laboratory practice would require at least an annual calibration check. On new installations, all parameters should be checked after the stabilization period.

  • Page 22: Alarms

    Section 3 Alarms The 700 Series ULT freezer alarms are displayed on the freezer control panel. When an alarm is active, the indicator next to the alarm description will light and there will be an audible alarm. Press the Silence key to disable the audible alarm for the ringback period.

  • Page 23: High Stage System Failure

    15 minutes. Probe Failure Alarm The microprocessor in 700 series freezers continually scans all probes including the control probe, heat exchanger probe and condenser probe to ensure that they are operating properly. Should an error be detected, the "Probe Failure"...

  • Page 24: Maintenance

    Maintenance Section 4 Clean Cabinet Exterior Wipe down the freezer exterior using soap and water and a general use laboratory disinfectant. Rinse thoroughly with clean water and dry with a soft cloth. Caution Avoid the excessive use of water around the control area due to the risk of electrical shock.

  • Page 25: Clean Water-Cooled Condenser

    Section 4 Maintenance Clean Water-cooled The water-cooled condenser can be cleaned-in-place by using the CIP procedure. Cleaning solutions can be used, depending on type of deposits Condenser or build-up to be removed. Do not use liquids that are corrosive to stainless steel or the brazing material (copper or nickel).

  • Page 26: Clean Lid Gasket

    Section 4 Maintenance 6. Remove the frost with a soft cloth. 7. After defrosting is complete, clean the interior with a non-chloride detergent. Rinse thoroughly with clean water and dry with a soft cloth. 8. Plug unit in and turn power switch on. 9.
  • Page 27 Section 4 Maintenance 7. Replace the recorder bezel. 8. Turn the battery power switch to Standby mode ( ). 9. Close lower panel door. Models 708, 709, 710, 711 1. Open the front door by grasping the handle and pulling. 2.

  • Page 28: Prepare Unit For Storage

    Section 4 Maintenance Prepare Unit for Defrost the unit as previously described. This will prepare the unit for storage. Turn off the battery power switch (O). Turn off the freezer power Storage switch. If the unit has been in service, turn it off and disconnect the power cord connector before proceeding with any maintenance.

  • Page 29: Preventive Maintenance

    Section 4 Maintenance PREVENTIVE MAINTENANCE Freezers Your equipment has been thoroughly tested and calibrated before shipment. Regular preventive maintenance is important to keep your unit functioning properly. The operator should perform routine cleaning and maintenance on a regular basis. For maximum performance and efficiency, it is recommended that the unit be checked and calibrated periodically by a qualified service technician.

  • Page 30: Factory Options

    Factory Installed Options Section 5 BUS - Back Up System Note Before installation of BUS components, make sure the power to the freezer is disconnected, the battery switch is turned off (O) and the freezer has warmed to ambient temperature. ▲...

  • Page 31: Install Temperature Probe

    Section 5 Factory Installed Options Install Injection Assembly 4. Remove the tape covering the end of the nipple and install the 1/8” NPT brass tee on the open end of the nipple. Place permagum sealant (continued) between the brass tee and the interior top. 5.
  • Page 32 Section 5 Factory Installed Options Install Temperature Probe 3. Carefully remove the existing Permagum sealant from around the probe port opening. (continued) Figure 5-4. Probe Access Port 4. Open the freezer lid and locate the probe cover on the upper front left wall.

  • Page 33: Connect Probe/Solenoid Harness

    Section 5 Factory Installed Options Connect Probe/Solenoid 1. Carefully coil the extra probe lead in the compressor compartment, and secure it to the compartment wall with a tie wrap and tie wrap Harness anchor provided. Additional tie wraps and anchors may be used to secure the probe lead to the exterior back wall of the freezer.

  • Page 34: Configure Optional Bus

    Section 5 Factory Installed Options BUS Control Panel (continued) Figure 5-6. BUS Control Panel Power - indicates the unit has AC power. Low Battery - battery charge is low. The battery needs replaced or recharged. Solenoid Engaged - BUS has opened the solenoid so it can inject gas (CO2 or LN2).

  • Page 35: Set Optional Bus Set Point

    Section 5 Factory Installed Options Set Optional BUS Set The optional back up system is designed to inject CO2 or LN2 into the freezer compartment if the temperature rises above back up system set Point point. To set the BUS set point: 1.

  • Page 36: Chart Recorder

    Section 5 Factory Installed Options Chart Recorder The following section describes the set up and operation of the optional chart recorder. Figure 5-7. Recorder Details Install Chart Paper 1. Open the plastic door of the recorder and press button #3 until the pen begins to move outward. 2.

  • Page 37: Datalogger

    Section 5 Factory Installed Options 5. When the desired program number is flashing, press button #3 to bring the pen arm back onto the chart. Recording will begin in the new program. Program From 30°C 60°C -100 38°C 50°C 100°C -100 200°C -115...

  • Page 38: Water-Cooled Condenser

    Section 5 Factory Installed Options Water-cooled The water-cooled condenser (P/N 195145, 195611) is a factory installed option and requires a qualified technician at freezer installation. The Condenser installation should include proper adjustment of the regulating valve, which controls the discharge pressure. Specifications for this option are displayed in Table 5-1.

  • Page 40: Specifications

    Specifications Section 6 Model Temperature Range -50°C(-58°F) to -86°C(-123°F) in 18°C to 32°C * (64.4°F to 89.6°F) ambient Exterior Dimensions 28.5”W x 43.8” H x 28.8” F-B (72.4cm x 111.3cm x 73.2cm) Add 7.9” (20.1cm) to F-B for wall spacer/handle. Interior Dimensions 18.5”W x 16.5”H x 18.5”...
  • Page 41 Section 6 Specifications Model Temperature Range -50°C(-58°F) to -86°C(-123°F) in an 18C to 32C * (64.4F to 89.6F) ambient Exterior Dimensions 72.0”W x 40.5” H x 28.8” F-B (182.9cm x 102.9cm x 73.2cm) Add 7.9” (20.1cm) to F-B for wall spacer/handle. Interior Dimensions 42.5”W x 28.0”H x 18.5”...
  • Page 42 Section 6 Specifications Model Temperature Range -50°C(-58°F) to -86°C(-123°F) in an 18C to 32C * (64.4F to 89.6F) ambient Exterior Dimensions 96.0”W x 40.5” H x 28.8” F-B (243.8cm x 102.9cm x 73.2cm) Add 7.9” (20.1cm) to F-B for wall spacer/handle. Interior Dimensions 66.5”W x 28.0”H x 18.5”...
  • Page 44 Section 7 Parts Thermo Fisher Scientific 7010708 7010708...
  • Page 45 Section 7 Parts 7010708 Thermo Fisher Scientific...
  • Page 46 Section 7 Parts Thermo Fisher Scientific 7010708...
  • Page 49 Section 7 Parts 7010708 Thermo Fisher Scientific...
  • Page 50 Section 7 Parts Thermo Fisher Scientific 7010708...
  • Page 51 Section 7 Parts 7010708 Thermo Fisher Scientific...
  • Page 52 Section 7 Parts Thermo Fisher Scientific 7010708...
  • Page 53 Section 7 Parts 7-10 7010708 Thermo Fisher Scientific...
  • Page 54 Section 7 Parts Thermo Fisher Scientific 7010708 7-11...
  • Page 55 Section 7 Parts 7-12 7010708 Thermo Fisher Scientific...
  • Page 56 Section 7 Parts Thermo Fisher Scientific 7010708 7-13...
  • Page 57 Section 7 Parts 7-14 7010708 Thermo Fisher Scientific...
  • Page 58 Section 7 Parts Thermo Fisher Scientific 7010708 7-15...
  • Page 59 Section 7 Parts 7-16 7010708 Thermo Fisher Scientific...
  • Page 60 Section 7 Parts Thermo Fisher Scientific 7010708 7-17...
  • Page 61 Section 7 Parts 7-18 7010708 Thermo Fisher Scientific...

  • Page 70: Electrical Schematics

    Section 9 Electrical Schematics Thermo Fisher Scientific 7010708...
  • Page 71 Section 9 Electrical Schematics 7010708 Thermo Fisher Scientific...
  • Page 72 Section 9 Electrical Schematics Thermo Fisher Scientific 7010708...
  • Page 74 Section 9 Electrical Schematics Thermo Fisher Scientific 7010708...
  • Page 75 Section 9 Section 9 Electrical Schematics Electrical Schematics 7010708 Thermo Fisher Scientific...
  • Page 76 Section 9 Electrical Schematics Thermo Fisher Scientific 7010708...
  • Page 78 Section 9 Electrical Schematics Thermo Fisher Scientific 7010708...
  • Page 79 Section 9 Electrical Schematics 7010708 Thermo Fisher Scientific...
  • Page 80 Section 9 Electrical Schematics Thermo Fisher Scientific 7010708...
  • Page 82 Section 9 Electrical Schematics Thermo Fisher Scientific 7010708 9-10...
  • Page 83 Section 9 Electrical Schematics 9-11 7010708 Thermo Fisher Scientific...
  • Page 84 Section 9 Electrical Schematics Thermo Fisher Scientific 7010708 9-12...

  • Page 86: Warranty

    Section 10 Warranty Information Thermo Fisher Scientific 7010708 7010708 10-1 10-1...
  • Page 87 Section 11 Warranty Information 10-2 10-2 7010708 7010708 Thermo Fisher Scientific...

  • Page 88: Appendix A Handling Liquid Nitrogen

    Handling Liquid Nitrogen Appendix A Warning Contact of liquid nitrogen or cold gas with the skin or eyes may cause serious freezing (frostbite) injury. ▲ Handle liquid nitrogen carefully. The extremely low temperature can freeze human flesh very rapidly. When spilled on a surface the liquid tends to cover it completely and intimately, cooling a large area.
  • Page 89 Appendix A Appendix A Handling Liquid Nitrogen Handling Liquid Nitrogen Introduction The safe handling and use of liquid nitrogen in cryogenic refrigerators and dewar flasks is largely a matter of knowing the potential hazards and using common-sense procedures based on that knowledge. There are two important properties of liquid nitrogen that present potential hazards: 1.
  • Page 90 Appendix A Handling Liquid Nitrogen Use proper transfer equipment. Use a phase separator or special filling funnel to prevent splashing and spilling when transferring liquid nitrogen into or from a dewar or refrigerator. The top of the funnel should be partly covered to reduce splashing.

  • Page 92: Appendix B Handling Liquid Co

    Handling Liquid CO Appendix B Warning High concentrations of CO gas can cause asphyxiation! OSHA Standards specify that employee exposure to carbon dioxide in any eight- hour shift of a 40-hour work week shall not exceed the eight-hour time weighted average of 5000 PPM (0.5% CO ).

  • Page 93: Appendix C First Aid

    First Aid Appendix C If a person seems to become dizzy or loses consciousness while working with liquid nitrogen or carbon dioxide, move to a well-ventilated area immediately. If breathing has stopped, apply artificial respiration. If breathing is difficult, give oxygen. Call a physician. Keep warm and at rest.
  • Page 98 Thermo Fisher Scientific Controlled Environment Equipment 401 Millcreek Road Marietta, Ohio 45750 United States www.thermo.com...
