Digilock Curve Product Manual

ASSIGNED USE FUNCTIONALITY
Aspire locks with a touch-free RFID interface are operated by an RFID credential or by an ADA compliant User Key. Manager
credentials (Manager Key or RFID credential) provide management access and/or external power. Programming is accomplished via
a Programming Key unique to the lock system. An optional mobile application tool simplifies lock system management and provides
audit trail for locks with advanced functionality.
LOCK PARTS
Front Unit
Key Slot
Pull Handle
Standard
RFID Credentials
RFID Card RFID Sticker
KEYS
Operates the lock
Overrides user access
Allows management inspection
Provides external power
Programs Manager Keys to the lock
Assigns user credentials
1 Up to 6 manager credentials (Manager Key or RFID credential) may be programmed to each lock. If managed with the optional Mobile App, up to 250 manager
credentials may be programmed to each lock.
2 One (1) Programming Key allowed per lock system.
3 Up to 20 user credentials (User Key or RFID credential) may be programmed to each lock. If managed with the optional Mobile App, up to 250 user credentials may be
programmed to each lock.
1
PR OD U CT G UI D E
Touch-Free RFID | Basic & Advanced
Reader
LED Usage Indicator
Shared Use
Assigned Use
RFID Keyfob RFID Wristband
3
Deadlatch Rear Unit
Cover Plate
Cover Plate Screw
Key Insertion
User Key Manager Key
•
Cable
½" (12.7 mm)
Deadlatch
Pin
Connection Options
Programming Key
1
• •
• •
• •
• •
•
•
2
