Ultrasonic sensor

Characteristic Curve

Characteristic response curve
Distance Y [mm]
1000
flat surface 100 mm x 100 mm
800
600
400
200
0
-200
-400
round bar, Ø 25 mm
-600
0 500 1000 1500 2000 2500
Y
wide sound lobe
X
narrow sound lobe
Accessories
UC-PROG1-USB
V15-G-2M-PVC
UB-PROG2
Microsoft .NET
Refer to "General Notes Relating to Pepperl+Fuchs Product Information".
Pepperl+Fuchs Group USA: +1 330 486 0001
www.pepperl-fuchs.com fa-info@us.pepperl-fuchs.com
3000 3500 4000
Distance X [mm]
Programming adapter
Female cordset single-ended M12 straight A-coded, 5-pin, PVC cable grey
Programming unit
Connection Software
Germany: +49 621 776 1111
fa-info@de.pepperl-fuchs.com
Singapore: +65 6779 9091
fa-info@sg.pepperl-fuchs.com
UC2000-L2M-E5-V15
4
