423RH, 423TB-18, 423TB-24, 423TP, 423TR
Oxford
Accessories
®
Operation & Maintenance Manual
Model Numbers
423RH
423TB-18
423TB-24
423TP
423TR
Modifications
-ORB
Oil rubbed bronze finish
-STN
Satin nickel finish
Note: Append appropriate -suffix to model number.
Robe Hook
18" Towel Bar
24" Towel Bar
Toilet Paper Holder
Towel Ring
Specifications
All premium accessories made from brass plated in
standard polished chrome finish.
Warranty
Limited Lifetime - to the original end purchaser in
consumer installations.
5 Years - for commercial installations.
Refer to www.symmons.com/warranty for complete
warranty information.
Advertisement
Table of Contents
Related Manuals for Symmons Oxford 423RH
Summary of Contents for Symmons Oxford 423RH
- Page 1 Limited Lifetime - to the original end purchaser in -ORB Oil rubbed bronze finish consumer installations. 5 Years - for commercial installations. -STN Satin nickel finish Refer to www.symmons.com/warranty for complete warranty information. Note: Append appropriate -suffix to model number.
- Page 2 Dimensions 423RH 423TR Measurements 2 5/8", 67 mm 2", 51 mm 2 3/4", 70 mm 6 7/8", 175 mm 7 3/4", 197 mm 4 3/8", 111 mm 423TP 5 7/8", 149 mm 2", 51 mm 7 7/8", 200 mm 4 3/8", 111 mm 18", 457 mm 423TB-18 20 1/8", 511 mm...
- Page 3 1) Clean finished trim area with a soft cloth using mild soap and water or a non-abrasive cleaner and then quickly rinse with water. ■ ■ ■ Symmons Industries, Inc. 31 Brooks Drive, Braintree, MA 02184 Phone: (800) 796-6667 Fax: (800) 961-9621 ■ ■ ■ ■ Copyright © 2018 Symmons Industries, Inc. symmons.com gethelp@symmons.com ZV-3092 REV 0 061418...
