Symmons Oxford 4200-TRM Operation & Maintenance Manual

Tub/hand shower trim

Advertisement

Quick Links

4200-TRM, 4201-TRM, 4202-TRM
Oxford
®
Tub/Hand Shower Trim Series
Operation & Maintenance Manual
Model Numbers
4200-TRM
4201-TRM
4202-TRM
Modifications
-1.5
1.5 gpm (5.7 L/min) flow restrictor
-2.0
2.0 gpm (7.6 L/min) flow restrictor
-ORB
Oil rubbed bronze finish
-STN
Satin nickel finish
Note: Append appropriate -suffix to model number.
1
Valve Trim
Shower Trim
Tub/Shower Trim
Specifications
Tub/shower trim with lever handle includes diverter
tub spout and 1 mode showerhead with standard
2.5 gpm (p.5 L/min) flow restrictor. Shower trim with lever
handle includes all of the above less diverter tub spout.
Valve trim with lever handle includes shower escutcheon
only. Components made from metal and nonmetallic
materials plated in standard polished chrome finish.
Compliance
-ASME A112.18.1; CSA B125.1
WARNING: This product can expose you to chemicals
including lead, which is known to the state of California
to cause cancer, birth defects, or other reproductive
harm. For more information, go to
www.P65Warnings.ca.gov.

Warranty

Limited Lifetime - to the original end purchaser in
consumer installations.
5 Years - for commercial installations.
Refer to www.symmons.com/warranty for complete
warranty information.
c

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Oxford 4200-TRM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Symmons Oxford 4200-TRM

  • Page 1 For more information, go to www.P65Warnings.ca.gov. Warranty Limited Lifetime - to the original end purchaser in consumer installations. 5 Years - for commercial installations. Refer to www.symmons.com/warranty for complete warranty information. Note: Append appropriate -suffix to model number.
  • Page 2 Dimensions Measurements 6 1/2", 165 mm 9 5/8", 245 mm 77", 1956 7 1/2", 191 mm 3 1/2", 89 mm 32", 813 mm (4202-TRM) 42", 1067 mm (4200-TRM, 4201-TRM) 12", 305 mm 2 9/16", 65 mm 4", 102 mm 1/2" NPT 4", 102 mm (Rough in) 2"...
  • Page 3 Parts Breakdown Replacement Parts Item Description Part Number Shower Arm 422SA Showerhead 422SH Handle Set Screw T-549 Flange Locking Ring T-543 Dome Cover Tub Spout 422TSD Gasket Shower Escutcheon T-542-NS-K001 Mounting Screws Mounting Plate Notes: 1) Append -ORB to part number for oil rubbed bronze finish;...
  • Page 4 Installation Note: 3) Install dome cover (H). Secure 6) Attach shower arm (A) to vertical For valve body installation, please with lock ring (D). shower pipe turning clockwise to see valve body installation guide. tighten. 1) Install mounting plate (K) to shower valve (4000-BODY).
  • Page 5 ■ ■ ■ ■ Symmons Industries, Inc. 31 Brooks Drive Braintree, MA 02184 (800)796-6667 Fax: (800)961-9621 ■ ■ ■ Copyright © 2018 Symmons Industries, Inc. www.symmons.com gethelp@symmons.com ZV-3052 REV A 080118...

This manual is also suitable for:

Oxford 4201-trmOxford 4202-trm
