442HSB
3 Mode Hand Shower Unit
Installation Guide
Model Numbers
442HSB
Options/Modifications
CG
-1.5
1.5 gpm (5.7 L/min) flow restrictor
-2.0
2.0 gpm (7.6 L/min) flow restrictor
-LHS
Less hand shower wand
-STN
Satin Nickel finish
Note: Append appropriate -suffix to model number.
Compliance
- ASME A112.18.1/CSA B125.1
Dimensions
C
3 Mode Hand Shower Unit
A
B
D
FLOOR
FLOOR
Canterbury
Feature Highlights
3 mode hand shower
3-1/4" diameter hand shower head
Dual checks for backflow protection
30" slide bar with cradle for hand shower mounting
60" flexible metal hose
Standard 2.5 gpm (9.5 L/min) flow restrictor
Shall be metal and nonmetallic construction, plated in
standard polished chrome finish
Warranty
Limited Lifetime - to the original end purchaser in
consumer installations.
5 Years - for commercial installations.
Refer to www.symmons.com/warranty for complete
warranty information.
E E
F F
Note: Dimensions subject to change without notice.
®
Measurements
A
Ø 1-1/2", 38 mm
B
2-1/8", 54 mm
C
28-9/16", 725 mm
(2x) Hole Size:
D
Ø 1/4", 6 mm
E
3", 76 mm
Male 1/2-14 NPT fitting must
F
be recessed 1/4" (6 mm)
from finished wall

Advertisement

loading
Need help?

Need help?

Do you have a question about the Canterbury 442HSB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Symmons Canterbury 442HSB

  • Page 1 Note: Append appropriate -suffix to model number. Limited Lifetime - to the original end purchaser in consumer installations. Compliance 5 Years - for commercial installations. Refer to www.symmons.com/warranty for complete - ASME A112.18.1/CSA B125.1 warranty information. Dimensions Measurements Ø 1-1/2", 38 mm 2-1/8", 54 mm...
