MINIPLEX Transponder Product Selection
Firefighters Telephone and General Audio Options
Model
Expansion Telephone Control Module with three Class B telephone NACS;
4100-1272
required when telephone circuits are mounted in transponder;
4100-1273 Telephone Class A Adapter Module; mounts on 4100-1272; no additional current required
4100-2320 Audio Bay-to-Bay Interconnection Harness Kit; order one for each audio bay addition
4100-0637 Audio Box Interconnection Harness Kit; order one for each close-nippled audio cabinet

Initiating Device Circuits (IDCs)

Model Description
4100-5005 Eight zones, Class B
4100-5015 Eight zones, Class A
Addressable Interface Modules
Model Description
4100-3101 IDNet Module, 250 point capacity
4100-3104 IDNet Module, 127 point capacity
4100-3105 IDNet Module, 64 point capacity
IDNet Modules, Specifications for each capacity
Model Description
MAPNET II Module, 127 point
4100-3102
capacity, add devices separately
MAPNET II Isolator Module, separates 127 input points into four isolated outputs,
4100-3103
mounts next to 4100-3102 only

Relay Modules

Model Description
4100-3201 Four DPDT relays, 2 A @ 30 VAC/VDC
4100-3202 Four DPDT relays, 10 A @ 250 VAC
4100-3203 Eight SPDT relays, 3 A @ 30 VAC/VDC
Current Calculation Notes:
1. To determine total supervisory current, add currents of modules in panel to base system value and all external loads powered
by panel power supplies.
2. To determine total alarm current, add currents of modules in panel to base system alarm current and add all panel NAC loads
and all external loads powered from panel power supplies.

General Specifications

Input Power
[System (SPS); Expansion
(XPS); Remote (RPS); TrueAlert Power
Supplies (TPS); and 100 W amplifiers]
Power Supply
Output Ratings
(System, Expansion, Auxiliary Power Tap 2 A maximum @ nominal 28 VDC
and Remote Power
Supplies)
Battery Charger Battery capacity range
(System and Remote
Charger characteristics
Power Supply)
Operating Temp. Range 32° to 120°F (0° to 49° C)
Environmental
Operating Humidity Range Up to 93% RH, non-condensing @ 90° F (32° C) maximum
Description
120 VAC Models
220-240 VAC Models
Total Power Supply 9 A total @ nominal 28 VDC, including module currents
Output Rating and auxiliary power outputs
NACs Programmed
2 A maximum per NAC, 5 A maximum @ nominal 28 VDC
for Auxiliary Power
6.2 Ah to 50 Ah; selectable via programming for batteries below 18 Ah; the SPS is
UL listed for up to 110 Ah battery charging for remotely located batteries
Temperature compensated, dual rate, recharges depleted batteries within 48
and performance hours per UL Standard 864, to 70% capacity in 12 hours per ULC Standard S527
With 250 IDNet devices, add
With 127 IDNet devices, add
With 64 IDNet devices, add
Module size 1 Block
Module without devices
Loading per IDNet device
Module size
Module without devices
Loading per MAPNET II device
Fully loaded module, total
These modules are nonpower-limited
and wiring must be routed away from
power-limited wiring.
4 A maximum @ 102 to 132 VAC, 60 Hz
2 A maximum @ 204 to 264 VAC, 50/60 Hz;
separate taps for 220/230/240 VAC
6
Size Supv. In Use
329 mA
1 Block 75 mA
max.
Size Supv. Alarm
1 Slot 75 mA 195 mA
1 Slot 75 mA 195 mA
Size Supv. Alarm
– 200 mA 250 mA
– 102 mA 127 mA
– 51 mA 64 mA
– 75 mA 115 mA
0.8 mA 1 mA
–
Size Supv. Alarm
2 Slots – –
– 270 mA 290 mA
– 1.7 mA 1.7 mA
– 470 mA 490 mA
1 Slot 50 mA 50 mA
Size Supv. Alarm
1 Slot 15 mA 75 mA
2 Slots 15 mA 175 mA
1 Slot 25 mA 280 mA
Output switches to
battery backup
during mains AC
failure or brownout
conditions
S4100-0035-2 5/02
