MINIPLEX Transponder Product Selection (Continued)
Audio Riser Modules
Model
Dual Channel Analog Audio Riser Module, accepts two separate audio signals from
4100-0621
host control panel; mounts in Block B, is controlled by Transponder Interface Module
3-8 Channel Digital Audio Riser Module; similar to analog module, except receives
4100-0622
and decodes a digital input signal with up to eight audio channels
Analog Emergency Voice/Alarm Communications Equipment*
Model
4100-1212 Flex-50, 50 W Amplifier, 25 VRMS output
4100-1213 Flex-50, 50 W Amplifier, 70.7 VRMS output
100 W Analog Amplifiers with Power Supply
Output
(VRMS)
Model
25 70.7
4100-1214
4100-1215
4100-1216
4100-1217
4100-1218
4100-1219
4100-1220
4100-1221
4100-1222
4100-1223
4100-1224
4100-1225
Digital Emergency Voice/Alarm Communications Equipment*
Model
4100-1226 Flex-50, 50 W Amplifier, 25 VRMS output
4100-1227 Flex-50, 50 W Amplifier, 70.7 VRMS output
100 W Digital Amplifiers with Power Supply
Output
(VRMS)
Model
25 70.7
4100-1228
4100-1229
4100-1230
4100-1231
4100-1232
4100-1233
4100-1234
4100-1235
4100-1236
4100-1237
4100-1238
4100-1239
Options for use with either Analog or Digital Amplifiers
Model
4100-1245 Flex-50 Expansion NAC Module
4100-1246 Flex-50 Class A Adapter Module
100 W Amplifier Expansion NAC
4100-1248
Module
4100-1249 100 W Class A Adapter Module
*Refer to document S4100-0034 for additional audio information.
