- Page 1 Grandstream Networks, Inc. GXV3470/3480/3450 IP Multimedia Phone for Android BroadWorks BLF User Guide...
-
Page 2: Table Of Contents
Table of Contents INTRODUCTION ......................4 OVERVIEW OF FUNCTIONS ..................5 Auto Provision the BLF List on the Phone ..................... 5 Visual Indicators ............................. 8 Directed Call Pickup ..........................9 Call Parking Notification ........................10 P a g e GXV3470/3480/3450 BroadWorks BLF User Guide... - Page 3 Table of Tables Table 1: The BLF Indicators Status in Different Scenarios ................8 Table of Figures Figure 1: Configure the SIP Account Settings ....................5 Figure 2: Configure Special Feature Option ....................6 Figure 3: Programmable Key General Settings .................... 6 Figure 4 Programmable Keys App on LCD ....................
- Page 4 P a g e GXV3470/3480/3450 BroadWorks BLF User Guide...
-
Page 5: Introduction
INTRODUCTION Busy Lamp Field (BLF) feature allows an end user, such as attendant, to monitor the hook status of a list of users. This document serves as an end user guide on how to configure Grandstream GXV3470/3480/3450 Multimedia phones for BroadWorks Busy Lamp Field feature. How to configure BLF on BroadWorks Application Server is out of the scope of this document. -
Page 6: Overview Of Functions
OVERVIEW OF FUNCTIONS Grandstream GXV3470/3480/3450 Enterprise Multimedia Phone for Android supports the BroadWorks Busy Lamp Filed feature. GXV3470/3480/3450 support this feature by changing the frame color of the block icons, associated with the monitored user, on the Account/Programmable Key widget. Additionally, the phone system is also able to pick up the calls to the monitored extensions. -
Page 7: Figure 2: Configure Special Feature Option
2. Configure Special Feature to “BroadSoft”, under Account → Special Features, as the figure shows below: Figure 2: Configure Special Feature Option 3. Configure web UI → Applications → Programmable Key → General Settings → Eventlist BLF URI. Note: Instead of configuring the ID and domain name, the URI needs to include the ID only. For example, if the BLF URI is blf1025@as.iop1.broadworks.net, it only needs to fill blf1025 in the box. -
Page 8: Figure 4 Programmable Keys App On Lcd
Figure 4 Programmable Keys App on LCD 5. The following screenshot is an example of the BLF entries provisioned on the Programmable Key app on LCD: Figure 5: BLF Entries on Programmable Key Widget P a g e GXV3470/3480/3450 BroadWorks BLF User Guide... -
Page 9: Visual Indicators
Visual Indicators The phone system can notify the end user the hook status of the monitored extension by changing the icon color and status. For example, the screenshot below shows the BLF indicators’ status when the extension 1014 places a call to the extension 1025. -
Page 10: Directed Call Pickup
(With “P” sign) (With “P” sign) Monitored extension not registered/BLF subscription failed Directed Call Pickup Directed call pickup feature allows the GXV34XX phone system to be able to answer the calls to the monitored users. This feature is very useful for the attendant to help the specified callees to answer the call if the callees are not available to answer it. -
Page 11: Call Parking Notification
The red dot in the following screenshot is the area, which the end user could tap to directed pick up the call: Figure 8: Directed Pickup on Programmable Key Call Parking Notification GXV34XX phones can display a parked indicator for the monitored extensions if an active call is parked on it. -
Page 12: Figure 9: Call Parking Notification On Programmable Key App
Figure 9: Call Parking Notification on Programmable Key App Figure 10 Call Parking Notification when Busy on Programmable Key App *Android is a trademark of Google LLC. P a g e GXV3470/3480/3450 BroadWorks BLF User Guide...
