Notes on warranty
The contents of this manual shall not become part
of, nor modify, any prior or existing agreement,
commitment or legal relationship. All obligations of
Sensus GmbH Ludwigshafen (and its affiliated
companies) arise from the respective purchase
contract, which also contains the complete and
solely valid warranty provision. These existing
warranty provisions are neither extended nor
limited by the information regarding the device
versions described in these instructions. The
content reflects the technical status at the time of
printing. We reserve the right to make technical
changes in the course of further development
without prior notice.
Recycling
The devices described in this manual
can be recycled. For environmentally
sound recycling and disposal, please
contact a certified waste management
company. This device contains a
lithium battery. In the interests of environmental
protection, this battery must not be disposed of with
normal household waste. The respective national
environmental regulations must be complied with.

2. Technical Data

Counter size q
Rated flow q
p
0.6
in m³/h
Minimum flow q
i
0.006
in m³/h
Accuracy class 3 or 2 in accordance with EN 1434
Ratio q /q 1:100, 1:50, 1:25
i p
Maximum flow q
s
1.2
in m³/h (short-term)
Starting flow in m³/h
0.0015
(Average values)
5 ... 105°C
Temperature
(-20 ... 105 °C for water/anti-freeze
measurement range
mixtures, not calibrated)
Temperature difference
3 ... 100 K
range
Switch-off threshold 0.15 K
Temperature: 4 sec.
Measurement cycles Flow and performance: 4 sec.
Energy and volume: 4 sec.
permissible temperature
5 ... 90°C
in the flow sensor
Flow at 0.1 bar pressure
0.5
loss in m³/h
Pressure loss at q in bar 0.15
p
k value
vs
(Flow at 1 bar pressure 1.53
loss in m³/h)
Permissible operating
16
pressure in bar
Length of connection PolluCom
cable approx. 0.3 m
Permissible ambient
5 ... 55°C
temperature
electromagnetic class Class E 1
M H 1500 INT, Page 4
0.6 q 1.5 q 2.5
p p p
1.5 2.5
0.015 0.025
3 5
0.0025 0.003
1.2 1.7
0.17 0.21
3.65 5.45
® F/S C, F/S CX:
PolluCom ® F/S C Heat/Cooling Meter
Installation and operating instructions
Mechanical class
Protection class
Battery life for
PolluCom ® F/S C, F/S CX,
*High ambient temperatures generally have a negative effect
on the service life
Various designs are directly compatible with third-
party products:
PolluCom F/S C RA: directly compatible with the
coaxial meter (A1/A34)
- Integral-MK MaXX
- CF Compact MK
- CF Sensor MK
PolluCom F/S C RI: directly compatible with the
coaxial meter (IST)
- Sensonic II
PolluCom F/S C RT: directly compatible with the
coaxial meter (TE1)
- Vario S
The compatibility with third-party products is clearly
marked on each variant of meters.
Example of a PolluCom F/S C RA

3. Important information

Applied standard: EN 1434, parts 1, 3 and 6
Heat and

instruments that must be handled with
extreme care. To protect them from damage
and contamination, do not remove them from
the packaging
assembly. The meter must not be carried by
the cable. Clean only with a cloth moistened
with water.
Class M 2
IP 54
8 years (with standard device
without communication)*
PolluCom F/S C
compatible with
Allmess
measuring
capsule meter
cold meters are measuring
until immediately before
