PolluCom ® F/S C Heat/Cooling Meter
Installation and Operating Instructions
Monthly value
consumption of external
pulse counter 1 (optional)
*
Monthly value
consumption of external
pulse counter 2 (optional)
*
Maximum flow in the
selected month incl. date
(average) *
Maximum flow in the
selected month incl. time
(average) *
Maximum efficiency in the
selected month incl. date
(average) *
Maximum efficiency in the
selected month incl. time
(average) *
Hours in error state *
Back to the month
selection (2 seconds hold
down)

7.4 Service level (L 4)

All display elements are marked with a human
symbol. The service level shows maximum values
and settings.
Error message
(only in case of an error)
Absolute maximum flow
rate incl. date *
Absolute maximum flow
rate incl. time *
Absolute maximum
efficiency incl. date *
Absolute maximum
efficiency incl. time *
Absolute maximum value
temperature in the warmer
pipe incl. date *
Absolute lowest value
temperature in the warmer
pipe incl. date *
Absolute maximum value
temperature in the colder
pipe incl. date *
Absolute lowest value
temperature in the colder
pipe incl. date *
Current date *
Current time *
Next cut-off date *
Days of operation *
Regulated battery voltage
Cumulative error hours *
Primary M-Bus address
(default setting: 0) *
Secondary M-Bus address
(factory default to:
meter serial number) *
Data transmission mode
(different length and
structure of the M-Bus
protocol) *
Firmware version
M H 1500 INT, Page 11
