Installation and Operating Manual
®
K
S
®
OTRON
MART
M
805 T
ODEL
R.F.
Capacitance
Level
Measurement
RF
RANSMITTER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KOTRON SMART RF 805 and is the answer not in the manual?

Questions and answers

Related Manuals for Magnetrol KOTRON SMART RF 805

Summary of Contents for Magnetrol KOTRON SMART RF 805

  • Page 1 ® OTRON MART 805 T ODEL RANSMITTER Installation and Operating Manual R.F. Capacitance Level Measurement ®...
  • Page 2 Nameplate: ton/crates against the packing slip and report any discrep- - partnumber - amplifier ancies to Magnetrol. Check the nameplate model number - serial n° (Model number/approvals as per inserted separate sheet) to - tag n° be sure it agrees with the packing slip and purchase order.
  • Page 3 11 V DC required – Current loop test LOOP CURRENT ® – points www.magnetrol.com Ground wire to green grounding screw or to external grounding screw Standard shielded twisted pair cable 100 % Customer supplied local current meter Non Ex...
  • Page 4 Enter a value between 1 up to 255 as your personal password with Display shows an encrypted value, enter your password Data is protected by a valid New Pass or call Magnetrol for assistance to recoop your password Password 4096 if necessary Protect data by new password...
  • Page 5 CALIBRATION - TRANSMITTER WITH LCD SCREENMENU: STEP BY STEP PROCEDURE Screen Action Comment *Level* Transmitter Display Transmitter default display. Level, % Output, and Loop *%Output* *Loop* values cycle every 5 seconds. Transmitter Display Transmitter displays Level measurement in cm or in. Level xx.x cm %Output...
  • Page 6 IMPORTANT: Check whether your HART ® communicator is equiped with the 805 Device Descriptors (DD’s). Older pur- chased devices may require an update – consult your local HART Service Centre or Magnetrol for further assistance. CONNECTIONS Connection of your Hart communicator: •...

  • Page 7: Maintenance

    (e.g., Mfgs. ID, Device #, account for Mfgs. ID #’s greater master software for upgrade. This is a Serial #, etc.) but will not read any than 63. Magnetrol’s ID is 86. shortcoming of early HART master process variables. software.

  • Page 8: Replacement Parts

    REPLACEMENT PARTS Item Description Part number Electronic module English display and HART ® 031-2809-001 French display and HART ® 031-2809-031 German display and HART 031-2809-041 ® Spanish display and HART ® 031-2809-021 HART ® only 031-2809-002 English display only 031-2809-003 French display only 031-2809-033 German display only...
  • Page 9 MAINTENANCE TROUBLESHOOTING FLOWCHART (LCD version) Start HART Unit Equipped Communications with Display? Active HART Check Voltage at Display has Text? Terminal Board See page 12 Some problems could be temporarily solved by power Check Power cycling the unit. Please call No Voltage? Supply and Wiring factory if this problem persists.
  • Page 10 MAINTENANCE TROUBLESHOOTING FLOWCHART (LCD version) Failure to Operate Display with Correct Loop Reseat Boards Retest Working? Inputs Check Loop Loop Current Remove Electronic Loop Current Current at Terminal Above 23 mA? Module Above 1 mA? Board Replace Electronic Replace Terminal Module Board Good...
  • Page 11 MAINTENANCE TROUBLESHOOTING FLOWCHART (LCD version) Unit with Display Communicates Call Factory "Software Error?" Corrupt Display Replace Electronic Text? Module "Uncal?" "Above Range?" "Corrupt "Shorted Probe?" Parameters?" Error "Open Probe?" "OSC Fail?" Displayed? Check Analog Check Calibration Parameters Parameters Check Probe and Connectors Same Error Check Offset and...

  • Page 12: Transmitter Specifications

    TRANSMITTER SPECIFICATIONS FUNCTIONAL/PHYSICAL Description Specification Power (at terminals) General Purpose: 11 to 36 V DC ATEX Intrinsically Safe: 11 to 28.6 V DC Signal Output 4-20 mA or 4-20 mA with HART ® 3.8 to 20.5 mA useable (meets NAMUR NE 43) Span minimum 5 pF - maximum 10.000 pF Zero and Range...

  • Page 13: Dimensions In Mm (Inches)

    DIMENSIONS in mm (inches) (3.28) (4.12) 45° View (8.43) (7.88) (4.94) (3.85) (4.38) Kotron 805 Housing front View 45° 2 cable entries Mounting Flange 220 (8.66) 220 (8.66) Optional Optional Mounting Mounting Flange Flange Probe 3/4" NPT Insertion 3/4" NPT Length 1"...
  • Page 14 Rigid probes: from 150 mm (6") to 6000 mm (20') insertion length Flexible probes: from 1 m (3,28') to 45 m (150') insertion length 3. OPTION: HART communicator Magnetrol P/N : 089 - 5213 - 012 (Euro Plug) 089 -5213 - 013 (UK Plug) 1. Code for SMART R.F. KOTRON ®...

  • Page 16: Service Policy

    SERVICE POLICY Owners of Magnetrol products may request the return of a control; or, any part of a control for complete rebuilding or replacement. They will be rebuilt or replaced promptly. Magnetrol International will repair or replace the control, at no cost to the purchaser, (or owner) other than transportation cost if: a.

Table of Contents
