oh happy day
YO U' V E REC E I VE D T HE D RE A M BOX !
It's already time for your first project. Let's get to work!
To make the process simple and easy to follow, we've broken down the DreamBox assembly
instructions into sections. The DreamBox pieces will come in 8 boxes. All of the hardware will
be found in a separate hardware box.
Our customer service team are the friendliest bunch of furniture experts. Do not hesitate to
reach out to them if you have questions at any point of the assembly process.
C U STO ME R SE RV ICE@ CR EATE RO O M .C O M
WW W.C R E AT E RO O M .CO M
U SA / CANADA : 8 01-2 26-26 8 6
U K / EU :
+4 9 40 6 9 6 3 2 9 55 O R + 4 4 7 759 33 58 6 8
We are excited for you to enjoy your inspiring new workspace and can't wait to see pictures!
Share your photos on Facebook and Instagram and don't forget to tag @createroomco.
Happy crafting!
DreamBox Assembly Instructions - Boswell Build
(Proprietary patented product and instructions. Do not copy or distribute.)
( M -F 9 A M -5PM M ST)
U102022

Advertisement

loading
Need help?

Need help?

Do you have a question about the DreamBox and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Create Room DreamBox

Summary of Contents for Create Room DreamBox

  • Page 1 It’s already time for your first project. Let’s get to work! To make the process simple and easy to follow, we’ve broken down the DreamBox assembly instructions into sections. The DreamBox pieces will come in 8 boxes. All of the hardware will be found in a separate hardware box.
  • Page 2 CENTER BOX (BOX 1 AND BOX 2) Box 1 includes: Center Box Side 1 (CB1), Center Box Side 2 (CB2), Center Box Shelf 2 (CB Shelf 2), Center Box Shelf 1 (CB Shelf 1), (2) Center Box Divider (CB Divider), Center Box Lid (CB Lid), Center Box Base (CB Base), Table 1 Box 2 includes: Center Box Upper Back (CB Upper Back), Center Box Lower Back (CB Lower Back), Center Box Middle Back (CB Middle Back), Table 2...
  • Page 3 Pre-drilled Wheel Bolt Center Box holes Top View Build on a blanket for best results Post hole g Side 2 g Side 2 CB Base Push (16) Wheel Bolts into top of CB base. Install (4) Caster Wheels onto Wheel Bolts. Secure Green dowel with (16) Wheel Nuts using 10mm wrench or drill with socket wrench extension.
  • Page 4 Insert (18 Locking Cams) into CB Shelf 1, CB Shelf 2, CB Lid in the following oreintation. Locking Cams (6) Locking Cams (6) Locking Cams (6) Install Locking Cams with the arrow pointing towards the edge of the wood.v Proprietary, patented product and assembly instructions. Do not copy or distribute.
  • Page 5 Center Box Stand CB 1 on its edge, finished edge up. Be sure posts, dowels & pins are aligned. Push CB 1 carefully into CB Base. tribute. Lock cams in place by turning 220 degrees. Use a shelf from your shelf bundle to support attached side pieces.
  • Page 6 Carefully fit CB Lid & CB Shelf 2 to **Finished edges facing up** CB Side 1. Be sure Posts are aligned with holes. Tap edges until secure. Slide CB dividers (2 & secure to CB Lid (4) #3 1 1/2 Confir in each divider.
  • Page 7 Posts (12) Insert (12) Posts into corresponding post holes in CB 2 & (2) Base Support in one at a time Pins to corresponding holes. & CB Shelf 2 using Install (1) Right Table Lift using (4) #1: 13 mm Euro Screws mat Screws Base Support Pins (2)
  • Page 8 Locking Cams (12) Tighten (12) Locking Cams until secure. *Note that 3 Locking Cams will insert into the TOP of Lid (outside of the box). #3 Screws (4) Slide CB dividers (2) in one at a time & secure to CB Lid & CB Shelf 2 using (4) #3: 1 1/2 Confirmat Screws in each divider.
  • Page 9 Carefully slide CB Back Panels into back grooves one at a time, start- ing with CB Lower Back. Be sure that holes are aligned with corresponding pilot holes. ct and assembly instructions. Do not copy or d e l f e l f Side 2 Screw in four corners of each...
  • Page 10 #1 Screws (9) Install (3) Folding Hinges Folding Hinges (3) with the barrel facing down to Table 1 using (9) #1: 13mm Euro Screws. ot copy or distribute. This side up. #1 Screws (15) Standard Hinges Turn Table 1 over and install (5) Standard Hinges with the barrel facing up to the other side using (15) 1 : 13mm Euro Screws...
  • Page 11 Slide Table 1 into Left and RightTable Lift slots as shown, matching 3 barrel-down hinges up with three hinge recesses on the top of CB Shelf 1. #1 Screws (9) Have one person pull Table 1 into the down position and hold while the other secures three recess hinges using (9) #1: 13mm Euro Screws.
  • Page 12 HEAVY TABLE! THIS STEP REQUIRES TWO PEOPLE. With Table 1 in the UP position, rest Table 2 on its edge, also in the UP position with the hinges facing out. LOCK into place with Barrel Locks. Attach (5) Standard Hinges to Table 2 with remaining (15) #1: 13mm Euro Screws adding one screw at a time to each hinge in rotation.
  • Page 13 To access storage below the table, lift table & lock in the “up” position. IMPORTANT: Table must be in “down” position before closing the DreamBox. CAUTION! HEA V Y TA BLE Use care when lifting table or changing heights. Always lock table “UP” when adjusting legs.
  • Page 14 LEFT AND RIGHT SIDE BOXES: BOX 3 & BOX 4 Box 3: (1) Door, (1) Right/Left Box Divider (R/L Divider), Left Box Side 1 (LB1), Left Box Side 2 (LB2), Left Box Base (LB Base), Left Box Lid (LB Lid), (1) Left Shelf (R/L Shelf).
  • Page 15 Left Side Box Shown. Build on a blanket for best results Push (16) Wheel Bolts into the top of the base. Install (4) Caster Wheels Wheel Locking onto bolts. Secure with (16) Wheel Nuts Bolts (16) Cams (6) using 10mm wrench or drill with socket wrench extension.
  • Page 16 Left Side Box Shown. Insert (3) Locking Cams into the top side of the lid. Turn cams 220 degrees Locking with phillips screwdriver Cams (3) until locked in place. *Note that Locking Cams will insert on the outside of the Posts (3) Install (2) Base Support Pins and (3) Posts Base Support...
  • Page 17 Left Side Box Shown. Build on a blanket for best results Insert (9) Posts HEAD DOWN into post holes on the edges of LB1 & LB2. Posts (9) To secure door, insert (9) Locking Cams along Slide CB dividers (2) in one at a ti Slide CB dividers (2) in one both sides of the interior of the box and turn with a Phillips Screwdriver until locked...
  • Page 18 #5: Screws (4) Screws into pilot holes to secure divider. #5: Screws (4) Divider MUST be installed manually to avoid damaging your DreamBox. Install (2) Angle Brackets at correspond- ing pilot holes in base and sides using (8) #5: 14mm Washer Screws...
  • Page 19 Right Side Box Shown. Build on a blanket for best results Push (16) Wheel Bolts into the top of the base. Install (4) Caster Wheels Wheel Locking onto bolts. Secure with (16) Wheel Nuts Bolts (16) Cams (6) using 10mm wrench or drill with socket wrench extension.
  • Page 20 Right Side Box Shown. Insert (3) Locking Cams into the top side of the lid. Turn cams 220 degrees with phillips screwdriver until locked in place. *Note that Locking Cams will insert on the outside of the Posts (3) Install (2) Base Support Pins and (3) Posts Base Support into bottom end of Side 1 as shown.
  • Page 21 Right Side Box Shown. Build on a blanket for best results Posts (9) Insert (9) Posts HEAD DOWN into post holes on the edges of RB1 & RB2. To secure door, insert (9) Locking Cams along both sides of the interior of the box and turn with a Phillips Screwdriver until locked in place.
  • Page 22 (4) #3: 1 1/2” Confirmat Screws into pilot holes to secure divider. Install (2) angle brackets at correspond- Divider MUST be installed manually to ing pilot holes in base and sides using (8) avoid damaging your DreamBox. 14mm washer screws.
  • Page 23 LEFT AND RIGHT SWING DOORS: BOX 5 and BOX 8 Box 5 includes: Left Swing Door Side 1 (LS1), Left Swing Door Side 2 (LS2), Right Swing Door Side 1 (RS1), Right Swing Door Side 2 (RS2), Left Swing Door Lid (LS Lid), Right Swing Door Lid (RS Lid), Swing Door Base (S Base)(2), Swing Back (S Back), (10) Swing Adjustable Shelves (S Shelf) Box 8: Pocket Shelf (2)
  • Page 24 Left Swing Door is Shown. Push in (8) Connecting Bolts into predrilled holes in LB Swing Lid Connecting Bolts (4) and LB Swing Base as shown. Push in (4) Connecting Bolts into predrilled holes in LS1 and LS2 as shown. Connecting Bolts (4) Connecting Bolts (2) Connecting Bolts (2)
  • Page 25 Screw in at a 45 degree angle. Screw in at a 45 degree angle. Attach LB Swing Lid to LB Swing Side 1. Insert Phillips head screwdriver at a slight angle into installed Locking Cams. Turn clockwise until tight. Slide Pocket Shelf over Connecting Bolts in LS1.
  • Page 26 Place LS2 on top of Lid and Pocket and fit over Connecting Bolts with Locking Cams. Tighten 2 Locking Cams on Lid and 2 Locking Cams on pocket. Two people may be needed for this step. Lift up LS2 slightly to slide the back panel into the grooves of LS1 and LS2.
  • Page 27 Attach S Base to LS1 and LS2 making sure that Connecting Bolts and Locking Cams are together. Tighten all 4 Locking Cams. Proprietary, patented product and assembly instructions. Do not copy or distribute.
  • Page 28 Attach the pill-shaped side of (1) Closed Swing Door Catch to the pre-drilled holes in the top left corner of the Left Swing Door using the included screws. Save the rectangular side for a later step. Closed Swing Door Catch Twist in 6 Metal Hooks to the bottom of the Open Swing...
  • Page 29 Attach the square metal side of (1) Open Swing Door Catch to LB1 of the Left Box using the included screws. Use pre-drilled holes to guide you. Open Swing Door Catch Closed Swing Door Catch Attach the rectangular side of (1) Closed Swing Door Catch to the pre-drilled holes in the top right corner of the left swing door...
  • Page 30 It is SAFE to use an Electric Screw Driver to install hinges. Turn Left Box onto LB2 and install (5) Offset Hinges to LB1 using (20) #1: 13 mm Euro Screws. With two people, attach Left Swing Door to CB 1 using (15) #1: Screws 13mm Euro Screws. #1 Screws Barrel faces down so that short side of...
  • Page 31 Right Swing Door is Shown. Connecting Bolts (4) Push in (8) Connecting Bolts into predrilled holes in RB Swing Lid and LB Swing Base as shown. Push in (4) Connecting Bolts into predrilled holes in RS1 and RS2 as shown. Connecting Bolts (4) Proprietar Proprietary, patented product and assembly instructions.
  • Page 32 phillips phillips kets kets washer washer Attach RS Lid to RS1. Insert Phillips head screwdriver at a slight angle into installed Locking Cams. Turn clockwise until tight (about 220 degrees). uctions. Do not copy or distribute. Slide Pocket over Connecting Bolts into RS1.
  • Page 33 in each divider. in each divider. Use ONLY a MANUAL phil Use ONLY a MANUAL Use ONLY a MANUAL screw driver. screw driver. screw driver. Install (2) angle brackets Install (2) angle brac Install (2) angle brac using (8) #5 14mm washe using (8) #5 14mm w using (8) #5 14mm w screws.
  • Page 34 Attach S Base to RS1 and RS2 making sure that Connecting Bolts and Locking Cams are together. Tighten all 4 Locking Cams. Proprietary, patented product and assembly instructions. Do not copy or distribute.
  • Page 35 Attach the pill-shaped side of (1) Closed Swing Door Catch to the pre-drilled holes in the top right corner of the Right Swing Door using the included screws. Save the rectangular side for a later step. Closed Swing Door Catch Open Swing Door Catch Twist in 6 Metal Hooks...
  • Page 36 Attach the square metal side of (1) Open Swing Door Catch to RB1 of the Right Box using the included screws. Use pre-drilled holes to guide you. Open Swing Door Catch Closed Swing Door Catch Attach the rectangular side of (1) Closed Swing Door Catch to the pre-drilled holes in the top right corner of the Right Swing Door...
  • Page 37 It is SAFE to use an Electric Screw Driver to install hinges. Turn Right Box onto RB2 and install (5) Offset Hinges to RB1 using (20) #1: 13 mm Euro Screws. With two people, attach Right Swing Door to RB1 using (15) #1: Screws 13mm Euro Screws. #1 Screws Barrel faces down so that short side of...
  • Page 38 (30) #1 Screws Use (4) 1” Door Screws to attach (2) Door Handles to the doors of your DreamBox. (The screws will be included with the Door Handles. Proprietary, patented product and assembly instructions. Do not copy or distribute.
  • Page 39 Push in (8) Connecting Bolts at shelf peg hole #20 from the top in to left & right boxes. Place L/R Shelf over Connecting Bolts with grooves and built-in cams facing down but visible on the underside of the shelf. Use a phillips screw driver to tighten cams until locked.
  • Page 40 BOX 6 & 7: Adjustable Shelves 1 & 2 Box 6: Center Box Long Adjustable Shelf (CB Long Shelf), (2) Center Box Middle 0.5” Adjustable Shelf (CB Middle Shelf), (4) Standard 0.5” Adjustable Shelf (Standard Shelf). Box 7: Center Box Long Adjustable Shelf (CB Long Shelf), (2) Standard 0.5” Adjustable Shelf (Standard Shelf), Center Box Middle 0.5”...
  • Page 41 three cheers YO U’ RE D OING GRE AT Now you are ready to start moving in! You can begin by customizing your tracks and totes to fit your organization needs. The instructions below will help you install your tracks correctly. e l f e l f e l f...
  • Page 42 80 T OT E M A XIMU M STO RAG E C ON F IGU RATION : Install tote tracks at shelf peg holes indicated by number, counting from the bottom. Count stationary shelf as a peg hole.
  • Page 44 Step 4 of The Create Room Journey. Visit http://www.createroom.com/pages/the-create-room-journey. For even more ideas and inspiration, join thousands of DreamBox owners in the Create Room Family Facebook Group @CreateRoomFamily. Be sure to share a picture of your new setup. We can’t wait to see how it turns out!
