oh happy day
YOU' V E RECEI VED THE S EW ST A T IO N !
Sewing is about to get a lot more fun—and convenient!
Follow simple steps to assemble your Sew Station. All necessary hardware is
included.
Our customer service team are the friendliest bunch of furniture experts. Do
not hesitate to reach out to them if you have questions at any point of the
assembly process.
C U ST O M ERS ERV I C E C R E A TE R O OM .C OM
W WW. CREA T ERO O M. COM
US A
CAN AD A: 80 1 2 2 6 2 68 6
U K
EU: + 4 9 4 0 6 963 2 95 5 OR + 4 4 7 7 59 3 35 8 68
We are excited for you to enjoy your inspiring new workspace and can't wait
to see pictures! Share your photos on Facebook and Instagram and don't
forget to tag @createroomco.
Happy crafting!
Sew Station Assembly Instructions
M F 9A M 5P M MS T
U052021

Advertisement

loading
Need help?

Need help?

Do you have a question about the oh happy day and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Create Room oh happy day

Summary of Contents for Create Room oh happy day

  • Page 1 YOU’ V E RECEI VED THE S EW ST A T IO N ! Sewing is about to get a lot more fun—and convenient! Follow simple steps to assemble your Sew Station. All necessary hardware is included.
  • Page 2 H A RDWA RE YOU ’LL NE ED (I NC LU DE D) : Table Legs 1” Screws w/ adjustable foot Table Leg Screws Door Handle (DreamBox Pull) Hinges 16” Drawer Rail Guides Connecting 270° Door Hinges Bolts 13mm Euro Screws White Magnetic Flathead Hinge 270°...
  • Page 3 Before you build your Sew Station & Spool Holder, you’ll need to separate the drawer rails into two pieces to be installed individually. The rails are comprised of three pieces. The outer and intermediate pieces don’t separate. The inner piece can be completely removed. outer track intermediate track inner track...
  • Page 4 Build on a blanket or rug to protect your wood panels. Push in (12) connecting bolts into the corresponding holes in Side 1, Side 2 and Back as shown. Side 1 Side 2 Back Now, pause to do some planning. Decide how you want to configure your Sew Station.
  • Page 5 R I G H T C ONF IG URATION (turn Top so that side table hinge holes are on the right) side table hinge holes Push in (7) connecting bolts into the corresponding holes in Top. L E F T C ONFIG URATI ON (turn Top so that side table hinge holes are on the left) side table hinge holes...
  • Page 6 RI G HT SIDE C ONF I GURATI ON Separate mounting plate from door hinge by pressing down silver lever (notice how it connects to make door install easier on step 20). Install (2) Door Hinge Mounting Plates to Side 2 as shown using a Phillips screwdriver &...
  • Page 7 R I G H T C ON FIGU RATI O N Side 2 Install (2) outer tracks over the spacers on Side 2 using (4) euro screws. L EFT C ON FIGU RAT IO N Side 2...
  • Page 8 Line up (3) built-in cams in Back with corre- sponding connecting bolts in Top. Slide Back into place. Back Insert a phillips head screwdriver at a slight angle and turn clockwise to tighten. Back...
  • Page 9 Slide Side 1 onto (2) connecting bolts in right side of Top and (3) built-in cams in Back. Turn clockwise to tighten. Note: If you chose “Right Side Configuration” the side table hinge holes will be on the same side of the Top as Side 1. If you chose “Left Side Configuration” the side table hinge holes will correspond with Side 2.
  • Page 10 Slide Side 2 onto (2) connecting bolts in left side of Top and (3) built-in cams in Back. Turn clockwise to tighten. Note: If you chose “Left Side Configuration” the side table hinge holes will be on the same side of the Top as Side 2. If you chose “Right Side Configuration” the side table hinge holes will correspond with Side 1.
  • Page 11 Using an electric phillips head screw- driver, install (4) angle brackets as shown using ((16) included screws. Side 2 Back Side 1 Lift Base onto (6) connecting bolts in Sides and Back. Tighten built-in cams to secure Base. Base Side 2 Back Lift Base into place...
  • Page 12 R I G H T SID E C ONF I GURATION Install magnetic catch with (2) included screws. Base Side 2 Back Side 1 Catch is adjustable. Move toward edge of Top. (Knee lift sewers with left side configuration will already havr door hinges installed in step 3.) L E F T S IDE C ONF IG URATION Base...
  • Page 13 Attach Side Table using (3) hinges and (18) R I G HT SID E C O NF IGURATI ON euro screws. DO NOT tighten screws all the way at first. Once table is attached tighten one screw in each hinge and repeat until all screws are tight.
  • Page 14 Attach Table using (5) hinges and (30) euro screws. DO NOT tighten screws all the way at first. Once table is attached tighten one screw in each hinge and repeat until all screws are tight. (LE FT S I DE C ON FIGU R ATIO N P ICTURED) Side 1 Base Back...
  • Page 15 Install (4) wheels using the included screws. Install with the largver hole towards the outside. Manually tighten. **larger hole towards the outside Side 1 Side 2 Back Side 2 Back Table Side Table With two people fold tables and turn onto front of Sew Station. Carefully lift onto 4 wheels.
  • Page 16 Next, you’ll assemble and install the machine electric lift & assemble the spool drawer. HAR DWAR E YO U ’L L N EED Bolts Nuts Rubber Washers Bearing pads wheels 1/2“ Screws. (2) for metal center, (6) for lift Cords Screws for Plastic Cord Shelf, (8) for installing lift to Sew Station.
  • Page 17 **You may want to use a piece of tape to keep lifter in place while assembling Install (4) bearing wheels onto the back 2 holes on each metal arm. Use (4) washers and (4) nuts. Use (2) 1/2” screws to fasten metal centerpiece to the power lifter.
  • Page 18 1/2” Screws Table 1/2” Screws 7/8“ Screws for metal center. Side 1 Side Table Side 2 Install power lifter using (8) 1/2” screws. If you have a left side configuration the unused pilot holes in the base will be visible after install on the left. If you have a right side configuration the unused pilot holes in the base will be on the right .
  • Page 19 Install lift control on right or left side of the Top using the included screws. Please install lift control switch on the OPPOSITE side of the rails. Attach cord using plastic cord holders to top and back of Sew Station. Install cords to power lift motor.
  • Page 20 S P O O L H OLD ER DRAW ER ASS EMB LY HAR DWARE YOU’LL NE E D Inner Drawer Guide screws Rail Guides Spool Holders Connecting Bolts Inner Shelf Supports Door Knob w/ Screws Acrylic Guards Right Shelf Supports Left Shelf Supports Spool Base Spool Side 1...
  • Page 21 Slide Spool Back onto (2) pre-installed connecting bolts on Spool Base. Spool Back Slide Spool sides onto (6) pre-installed connecting bolts and attach to Spool Back and Spool Base. Spool Back Attach Spool Shelf to (6) connecting bolts on Spool Sides and Spool Back. Spool Back...
  • Page 22 S P O OL H OL D ER ON RI GHT inner track Spool Back Using (8) guide screws attach (2) inner track rails to the back of Spool Back. S P O O L HOL D ER ON LE FT (For machine knee lift sewists) Spool Back...
  • Page 23 Spool Drawer Installation RI G H T SID E C ONF I G UR ATION Table Table Side 1 Side 2 Install drawer knob with includ- ed drawer knob bolt. Line up rails and push drawer in until you hear a ‘click’. LE F T SID E C ON F I GURATION Table Side 1...
  • Page 24 Install (2) 270° hinges using (4) flathead hinge screws Install magnetic strike plate using included screw. Install door support wheel using the included screws. See below for Left and Right side installation. LE F T S I D E C O N F I GU R AT I ON R I GHT S IDE C ON F IG U R AT I O N Install magnetic strike plate using provided screw.
  • Page 25 R I G H T SID E C ONF I GURATI ON Push onto bracket and click in place. LE F T S I D E C ONF IG UR ATI ON...
  • Page 26 R I G H T S ID E C ONF IGURATI ON Install (4) hinges to attach the doors together, using (24) Euro screws. Make sure doors are horizontally aligned before tightening screws. Add the door handle and (2) screws. LE FT S ID E C ONF I G UR ATI ON...
  • Page 27 Install 9 shelf-supports in suggested placement. If spool holder is installed on the left for knee lift sewers, 2 shelves will be installed on the right. You may not be able to install the middle shelf, giving you plenty of room for the motion of your knee lift.
  • Page 28 Using the palm of your hand snap 16 spool pegs into two peg holder shelves. Install 8 shelf supports at an angle to install 2 spool shelves.
  • Page 29 You can attach the Sew Station to the DreamBox, WorkBox 3.0 or Her Hobby Box using the Sash Lock and Barrel Lock. Underside view...
  • Page 30 Apply the Left and /or Right Side Guide Sticker to Left/Right Corner of the DreamBox table. Be sure sticker is up against the front outside edge of the table. Use the provided screws to attach (1) Sash Lock Catch (per side) with the hook near the edge of the table using the sticker as a guide.
  • Page 31 yipee! YOU’VE DONE IT. Now sit back and enjoy your new inspiring sewing space. That first project is going to feel so good! Remember to share pictures of your crafts and and craft space with us on Face- book @CreateRoomFamily.
