Operation and Maintenance
Manual
Electronic Laboratory Autoclaves
Models 5050, 5075 EL-MD/EL-D
EL-MD: standard autoclave (manual door)
EL-D: standard autoclave (automatic door)
C: optional system for fast cooling
PV: optional vacuum pump
BH: optional bio hazard filtration
F: optional fan for super-fast cooling
Cat. No. MAN205-0469000EN Rev. L
Tuttnauer Europe B.V.,
Hoeksteen 11 4815 PR P.O. Box 7191 4800 GD Breda,
The Netherlands  Tel: 31 (0) 765423510,  Fax: 31 (0) 765423540

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5050 and is the answer not in the manual?

Questions and answers

Related Manuals for Tuttnauer 5050

Summary of Contents for Tuttnauer 5050

  • Page 1 Operation and Maintenance Manual Electronic Laboratory Autoclaves Models 5050, 5075 EL-MD/EL-D EL-MD: standard autoclave (manual door) EL-D: standard autoclave (automatic door) C: optional system for fast cooling PV: optional vacuum pump BH: optional bio hazard filtration F: optional fan for super-fast cooling Cat.

  • Page 2: Table Of Contents

    3.8 Construction ................... 15 3.9 Environment Emission Information ..........15 3.10 Overall Dimensions -- EL5050-MD/ EL5050-D ....... 16 3.11 Overall Dimensions -- ELCPV 5050-MD/ ELCPV 5050-D ....17 3.12 Overall Dimensions -- ELPRC 5075-MD/ ELPRC 5075-MD .... 18 3.13 Specifications ................. 19 3.14 Stickers Description ...............
  • Page 3 5.8 Program 8: Bio Hazard 2 (BH, bio-hazard models only) ....39 5.9 Program 9: Bio Hazard Liquids (BH, bio-hazard models only) ..40 5.10 Program 10: Vacuum Test (PV, pre-vacuum models only) ..... 42 5.11 Program 11: Warm-Up ..............43 5.12 Program 12: Isothermal ..............
  • Page 4 10.10 Unloading .................. 83 10.11 Start Cycle by Clock mode ............84 Service and Maintenance Instructions ............ 85 11.1 Preventive and Scheduled Maintenance ........85 11.2 Draining the Reservoir ..............86 11.3 Cleaning water strainer ..............87 11.4 Checking the Safety Valve ............. 89 11.5 Moving the Autoclave ..............

  • Page 5: General

    General Read the Operating Instructions carefully, before beginning any operation on the autoclave! Introduction Model 5050/5075 EL-MD/EL-D is a laboratory sterilizer designed especially for the sterilization of instruments, liquids, and other materials in hospital laboratories, medical laboratories (including the medical...
  • Page 6 A special feature of the autoclave is fast cooling stage for liquids. In this stage pressure in the chamber is increased by means of compressed air to compensate the fast decreasing of pressure due to the fast cooling. The fast cooling shortens the time required for safe handling of bottles.

  • Page 7: Incoming Inspection

    All Tuttnauer products are carefully inspected prior to shipment and all reasonable precautions are taken in preparing them for shipment to assure safe arrival at their destination.

  • Page 8: Warranty Statement

    (14) days of purchase or the warranty will be void. Our Technical Service Depts can be reached at:  Tuttnauer Europe b.v., Hoeksteen 11, 4815 PR, Breda, P.O. Box 7191, 4800 GD Breda, Netherlands. +31/76-5423510, Fax: +31/76-5423540, E-mail: info@tuttnauer.nl Note: If there is any difficulty with this instrument, and the solution is not covered in this manual, contact our representative or us first.

  • Page 9: Safety Instructions

    Safety Instructions The autoclave has unique characteristics. Please read and understand the operation instructions before first operation of the autoclave. The following issues may require instructions guidance provided by the manufacturer: how to operate the autoclave, the door safety mechanism, the dangers involved in circumventing safety means, how to ensure that the door is closed, and how to select a correct sterilization program.
  • Page 10 Before withdrawing trays, wear heat resistant gloves. Before opening the door, verify that there is no pressure in the chamber (chamber pressure gauge is located on the autoclave's front panel). Open the door slowly to allow steam to escape and wait 5 minutes before you remove the load.

  • Page 11: Technical Data

    Technical Data Directives and Standards Every autoclave meets the provisions of the following Directives and is in compliance with the following Standards: ISO 9001: Quality Management System ISO 14001: Environmental Management System ISO 17025: General requirements for the competence of testing and calibration autoclaves ASME Code Section I and section VIII.

  • Page 12: Water Quality

    Water quality The distilled or mineral-free water supply shall be according to the table below: Suggested maximum limits of contaminants in water for steam sterilization per EN13060 Substance Feed Water Condensate ≤ 10 mg/l ≤ 1.0 mg/l Evaporate residue ≤ 1 mg/l ≤...

  • Page 13: Electrical Data

    RO maintenance requirements are less demanding than those of the DI units. Therefore, the use of mineral free water will contribute to better performance and longer life of the autoclave. Electrical Data 230V configuration Property Value: 5050 Value: 5075 4400W 6600W Total Power (4*1100W) (6*1100W)

  • Page 14: Stand - By Heating Mode

    400V configuration Property Value: 5050 Value: 5075 4400W 6600W Total Power (4*1100W) (6*1100W) Voltage 3Ph, 400VAC 3Ph, 400VAC Amperage Protection against electrical IEC 61010-1 shock Mains supply fluctuation +/- 10% Stand – by heating mode The autoclave provides an option of heating the chamber in stand-by mode between cycles with a very low power to reduce total cycle time (1.6% of the total power only).

  • Page 15: Utilities

    Voltage 3 Ph, 5075 6 x 1100W IEC 61010-1 400V/50Hz 3 Ph, 5050 4 x 1100W IEC 61010-1 400V/50Hz Attention: The electrical net must be protected with a current leakage safety relay. The electrical network must comply with local rules or regulations.

  • Page 16: Construction

    Construction The main parts of the autoclave are made of materials as indicated below:  Chamber and door are made of stainless steel.  Trays are made of stainless steel.  Water reservoirs are made of stainless steel.  Door handle (MD models) is made of hard plastic material, which is safe to touch and thermo-insulated.

  • Page 17: Overall Dimensions -- El5050-Md/ El5050-D

    Overall Dimensions -- EL5050-MD/ EL5050-D 3.10 Page 16...

  • Page 18: Overall Dimensions -- Elcpv 5050-Md/ Elcpv 5050-D

    Overall Dimensions -- ELCPV 5050-MD/ ELCPV 5050-D 3.11 Page 17...

  • Page 19: Overall Dimensions -- Elprc 5075-Md/ Elprc 5075-Md

    Overall Dimensions -- ELPRC 5075-MD/ ELPRC 5075-MD 3.12 Page 18...

  • Page 20: Specifications

    Specifications 3.13 Model 5050 5075 Property Height 740mm 740mm Overall Width 860mm 860mm dimensions Length 890mm 1120mm Width 940mm 940mm Maximum dimensions (door Height 740mm 740mm open) Length 1460mm 1700mm Distance Width between Length supporting legs Net weight (kg) 203kg...

  • Page 21: Stickers Description

    Displayed = 10 sec. Do not Touch LAB048-0462 On the door frame Microswitches behind the door please Contact cover Tuttnauer Service Do not Touch LAB048-0463 On the door frame Microswitches behind the door please Contact cover Tuttnauer Service...

  • Page 22: Front View

    Front View 3.15 Description Description Main switch (under the printer Autoclave cover cover) Validation port (under door cover) Safety valve Pressure gauge Water reservoir cover Reservoir water drain valve (under Water reservoir – assembly door cover) Ring for drain valve (under door cover) Control panel display Printer Cover Control panel keyboard...

  • Page 23: Rear View

    Rear View 3.16 Description Cut off Circuit breaker Electricity Strainer Drain Tap Water Air Inlet Page 22...

  • Page 24: Control Panel

    Control Panel Control Panel Drawing No. Description Display Keypad: Up Button Keypad: Start/Stop Button Keypad: Down Button Printer Page 23...

  • Page 25: Description And Functions Of The Front Panel Keyboard

    Description and Functions of the Front Panel Keyboard The front panel is composed of 3 sections: Display screen. Keypad. Printer Display screen The display is an LCD panel used to display the current status of the autoclave while using Operational Messages and Error Messages. •...
  • Page 26 Keypad The keypad consists of three keys as described below: UP key This key has the following functions: • In the menu directories: This key enables the operator to browse through the cycles. • In the directories available: When the cursor is blinking on a number, the UP ▲ key increases its value.

  • Page 27: Displayed Error Messages / Symbols

    START/STOP key enables moving to the next position. When the cursor is blinking on a menu selection, the START/STOP key activates that selection. Printer The printer is an optional device. It prints the detailed history of each cycle performed by the autoclave. The printing is on thermal paper with 24 characters per line and records the sterilization cycle information for subsequent consideration.
  • Page 28 Enter the Admin menu as This symbol is displayed described in this manual to when Cycle by Clock mode is change the time or to cancel performed. this option. This message is displayed if Enter the Admin menu as the user presses Cycle by described in this manual to START/STOP key while the...

  • Page 29: Sterilization Programs

    Sterilization Programs Sterilization Programs Temp. models models models only only only Icon Name 134°C Glass (273F) 121°C Plastic (250F) 121°C Liquid A (250F) Liquid B – 121°C Waste* (250F) Liquid A – 121°C √ Cooling* (250F) Liquid B 121°C √ Waste (250F) Cooling*...
  • Page 30 Sterilization Programs Temp. models models models only only only Icon Name Bio Hazard √ Liquids* (250F) √ Vacuum test (PV 5 +10 only)* 80 °C Warm-Up* 176F) 80 °C Isothermal* 176F) 121C Mixture* (250F) 121C Glass Test* (250F) 121C Durham* (250F) *These programs are optional.
  • Page 31 During the process, the stages of the cycle will be displayed on the screen: The stages names are as follows: Start Pulse Low (PV models only) Pulse High (PV models only) Heating Sterilization Cooling (C models only) Exhaust Drying (PV model only) Ending Page 30...

  • Page 32: Program 1: Glass

    Program 1: Glass For glass instruments when the manufacturer recommends autoclaving at temperatures of 134C (273F). Drying stage is available for PV (pre-vacuum) models only. Nominal parameters default settings • Sterilization temperature: 134C (273F). • Sterilization time: 3 minutes. • Drying time: 1 minute.

  • Page 33: Program 2: Plastic

    Program 2: Plastic For plastic and other delicate instruments when the manufacturer recommends autoclaving at temperatures of 121C (250F). Drying stage is available for PV (pre-vacuum) models only. Nominal parameters default settings • Sterilization temperature: 121C (250F) • Sterilization time: 15 minutes •...

  • Page 34: Program 3: Liquid A

    Program 3: Liquid A For liquids when the manufacturer recommends autoclaving at temperatures of 121C (250F) for 15 minutes. Cautions! Both PT100 temperature sensors must be inside the bottles. For proper sterilization, fill the bottles with approximately the same amount of liquid. Nominal parameters default settings •...

  • Page 35: Program 4: Liquid B - Waste

    Then steam is exhausted out of the chamber at a fast rate until pressure decreases to ambient pressure. • Drying: N/A • Ending: The system checks that End temperature and End pressure have been reached, and then releases the door. Program 4: Liquid B –...

  • Page 36: Program 5: Liquid A - Cooling (C - Cooling Models Only)

    • Sterilization: Sterilization temperature is maintained constant during the sterilization time. • Cooling: N/A • Slow Exhaust: Steam is exhausted from the chamber at a slow rate, until it reaches the pressure of 30 kPa above the ambient pressure. Then steam is exhausted out of the chamber at a fast rate until pressure decreases to ambient pressure.

  • Page 37: Program 6: Liquid B - Waste Cooling (C - Cooling Models Only)

    Operations sequence: • (PV, pre-vacuum models only) Pulse low/Pulse high: at one pulse it will build vacuum down to 25 kPa. • Water Inlet: Water enters the chamber. • Heating: The chamber is heated by actuation of electrical heaters until the sterilization temperature is reached. •...

  • Page 38: Program 7: Bio Hazard 1 (Bh, Bio-Hazard Models Only)

    Nominal parameters default settings • Sterilization temperature: 121C (150F). • Sterilization time: 30 minutes. Operations sequence: • (PV, pre-vacuum models only) Pulse low/Pulse high: at one pulse it will build vacuum down to 25 kPa. • Water Inlet: Water enters the chamber. •...
  • Page 39 temperatures of 134C (273F) for 30 minutes. Drying stage is available for PV (pre-vacuum) models only. Nominal parameters default settings • Sterilization temperature: 134C (273F) • Sterilization time: 30 minutes • Drying time: 1 minute. (PV – pre-vacuum models only). Operations sequence: •...

  • Page 40: Program 8: Bio Hazard 2 (Bh, Bio-Hazard Models Only)

    Program 8: Bio Hazard 2 (BH, bio-hazard models only) All exhaust from the chamber before completion of the Sterilization stage is performed through the bio-hazard filter. For instruments when the manufacturer recommends autoclaving at temperatures of 121C (250F) for 45 minutes. Drying stage is available for PV (pre-vacuum) models only.

  • Page 41: Program 9: Bio Hazard Liquids (Bh, Bio-Hazard Models Only)

    • Note: If the cycle fails, fast exhaust is performed through the bio- hazard filter. Some water may remain in the chamber after a failed cycle. To remove such water, press Start and repeat the cycle. If the problem persists, call for service. •...
  • Page 42 Operations sequence: • (PV, pre-vacuum models only) Pulse low/Pulse high: at one pulse it will build vacuum down to 25 kPa. All exhaust from the chamber is performed through the bio-hazard filter. • Water Inlet: Water enters the chamber. • Heating: The chamber is heated by actuation of electrical heaters until the sterilization temperature is reached.

  • Page 43: Program 10: Vacuum Test (Pv, Pre-Vacuum Models Only)

    Program 10: Vacuum Test (PV, pre-vacuum models 5.10 only) Vacuum Test is a test program with the following parameters: Caution! This is not a sterilization program! Nominal parameters default settings • Vacuum pressure: 17.0 kPa • Vacuum time 1: 5 minutes •...

  • Page 44: Program 11: Warm-Up

    Program 11: Warm-Up 5.11 Pre-warming the chamber at 80C (176F) without drying. Caution! This is not a sterilization program! Nominal parameters default settings • Warm-up temperature: 80C (176F). • Warm-up time: 20 minutes. Operations sequence: • Pulse low/Pulse high: N/A •...

  • Page 45: Program 12: Isothermal

    Program 12: Isothermal 5.12 For liquids when the manufacturer recommends autoclaving at 60- 100C (140-212F) with no drying. Recommending for melting of agar, pasteurization etc. Put one PT100 inside the bottle, leave the second one hanging in the chamber outside the bottle (see below). Nominal parameters default settings •...

  • Page 46: Program 13: Air Mixture

    • Keep Heat: Keep-Heat temperature is maintained constant for the preset Keep-Heat time. • Cooling: N/A. • Fast Exhaust: the steam is exhausted out of the chamber at a fast rate until pressure decreases to ambient pressure. • Drying: N/A •...

  • Page 47: Program 14: Glass Test

    Nominal parameters default settings • Sterilization temperature: 121C (250F). • Sterilization time: 15 minutes. Operations sequence: • Heating: Air enters the chamber followed by steam that heats it up until the sterilization temperature is reached. Air adds pressure needed to prevent swelling or warping of soft plastic items. Chamber fan is used to mix air with steam.
  • Page 48 Cautions! Both PT100 temperature sensors must be inside the bottles. For proper sterilization, fill the bottles with approximately the same amount of liquid. Nominal parameters default settings • Sterilization temperature: 121C (250F). • Sterilization time: 20 minutes. Operations sequence: • Heating: Steam enters the chamber and heats it up until the sterilization temperature is reached.

  • Page 49: Program 15: Durham

    Program 15: Durham 5.15 For liquids when the manufacturer recommends autoclaving at temperatures of 121ºC (250F) for 15 minutes. Cautions! Both PT100 temperature sensors must be inside the bottles. For proper sterilization, fill the bottles with approximately the same amount of liquid. Nominal parameters default settings •...
  • Page 50 • Drying: N/A • Ending: The system checks that End temperature and End pressure have been reached, and then releases the door. Page 49...

  • Page 51: Screens

    Screens Screens following a completely successful cycle – "Cycle Ended" 1. System Ready 2. Pulse Low (PV Pulse High (1/1) (PV model only) model only) 2. Insert Water 3. Heating 4. Sterilization 5. Exhaust 5. Drying (PV model 6. Ending only) 7.

  • Page 52: Screens Following Aborted Cycles After Complete Sterilization Stage

    Screens following aborted cycles after complete sterilization stage The sterilization phase ended successfully – cycle ended, and the reason of failure is displayed. For example, the next two scenarios: Canceled by user after complete sterilization stage The cycle ended successfully, the reason for aborted cycle is displayed.
  • Page 53 Failure according to Pressure Time Error Failure according to Cancellation by user before complete sterilization stage When "Cycle Failed" appears on the screen, the user shall press START/STOP key to delete the "Cycle Failed" message An example for all displayed warnings according to Cycle Failed: Cycle Failed message Reason of failure...

  • Page 54: Checking And Changing Parameters And Other Data

    Checking and Changing Parameters and other data Bacsoft control panel allows changing parameters of the cycle and of the system, exporting various data to, and importing from, a USB device or to the printer, and some other options. Cycle parameters are changeable for Custom programs only (see Duplicate cycles), except for the Temperature sensors, Displayed inputs, and Dry Time.

  • Page 55: Changing A Parameter

    Note: To exit every screen and to return to the previous screen (to get one level up): • Move the cursor to Exit by pressing the UP or DOWN keys and then press the Start/Stop key. - or- • Press the UP and DOWN keys simultaneously. In the next chapter you will see how to change the required parameter as desired.
  • Page 56 Note: Please note the maximum and minimum values for this parameter shown on the screen. Your value must be within these boundaries. Below is the example of changing the Dry time parameter on the screen used in the previous section: Page 55...

  • Page 57: Quick Options Screen

    Note: To exit every screen and to return to the previous screen: • Move the cursor to Exit by pressing the UP or DOWN keys and then press the Start/Stop key - or- • Press the UP and DOWN keys simultaneously. Quick options screen When the autoclave is on and no cycle is running, press Up and Down keys simultaneously to enter the Quick options screen.
  • Page 58 Below you can find instructions how to login and enter the Main menu. Section 7.1 above explains how to browse through the menus; section 7.2 explains how to change a parameter. Below is the explanation of some Quick Options. Version Information This directory allows viewing information of the current, factory default, and previous software versions.
  • Page 59 Start cycle by clock This subdirectory enables the operator to start the cycle at the time set by this parameter. Enter the Start cycle by clock screen. The following screen will appear: On the Start cycle by clock screen, the time is displayed in the form “HH:MM”.
  • Page 60 Exit the Enabling the Start Cycle by Clock. The start cycle by clock icon appears on the display: Disabling the START CYCLE BY CLOCK On the Start Cycle by Clock screen, move the cursor to Disabled. Press Up or Down key to disable Starting cycle by clock. Exit the Enabling the Start Cycle by Clock.
  • Page 61 On the Set date and time screen, the time is displayed in the upper row in the form "HH:MM: SS". The hour range is 24 hours (i.e., from "0" to "24"). The date is displayed in the lower row in the form "DD: MMM: YYYY".

  • Page 62: Logging In And Entering The Main Menu

    Logging in and entering the Main menu Below you can find instructions how to login and enter the Main menu. Section 7.1 above explains how to browse through the menus, section 7.2 explains how to change a parameter. When the autoclave is on and no cycle is running, press the up and down keys simultaneously to enter the Quick Options screen (see 7.3).

  • Page 63: Changing Parameters

    • Set the code to 0001. You will get to the Main menu. Below is the list and the explanation of some options available to user on the Main Menu. Changing parameters Bacsoft control panel provides an interface that consists of control screens available through an easy scrollable menu tree.

  • Page 64: System Parameters

    System Parameters This menu is listing the system parameters that are the same for all cycles. Browse to the following folder: Main menu\System parameters You will see the following screen: Screen Saver In this menu you can define the screensaver delay time, i. e. how long the keyboard will be untouched before the screensaver activates.

  • Page 65: Maintenance

    Change the parameter as desired. Maintenance Maintenance procedures provided by Bacsoft software allow you additional tests and USB input/output options. Browse to the following folder: Main menu\Maintenance You will see the following screen listing the maintenance options: Below is the instruction for autoclave’s maintenance menu. Reset atmospheric pressure In this menu you can reset the atmospheric pressure value.
  • Page 66 Leave the door open for 2 minutes at least. Ambient temperature should be less than 45°C. Note: Please reset the atmospheric pressure when you install the autoclave for the first time, and each time you relocate or calibrate the autoclave. Printer test In this menu you can check the normal function of the printer.

  • Page 67: Cycle Parameters

    Cycle parameters The Cycle parameters menu includes parameters of a specific sterilization program (cycle). Browse to the following folder: Main menu\Cycle parameters You will see the following screen listing the cycle parameters: Note: For all the standard sterilization cycles, and for Bowie and Dick test, the only changeable cycle parameter is dry time (you will not see other parameters on your screen).
  • Page 68 Add Dry Time This subdirectory allows you to change the Dry Time parameter for the current cycle. Browse to the following folder: Cycle parameters\Drying\Add Dry Time Change the parameter as desired. Page 67...

  • Page 69: Printer

    Printer Printer Output The printing is on thermal paper with 24 characters per line and contains the following information: • Date: • Time: • Ser. Num: • Model: • Version: • Cycle Num: • Cycle: • Dry Time: • Ster Temp: •...
  • Page 70 Printer output Description ____________ Operator To be filled in manually by operator Time: 12:14:47 Time sterilization cycle ended Status: Cycle Ended 00:24:43 101.3 099.7 Cycle finished time D 00:31:23 101.9 023.4 The time, temperature, and pressure during drying The time, temperature, and pressure during D 00:28:23 106.2 109.7...
  • Page 71 TIME °C End Temp: 120.0 °C Ster Time: 7.0min Sterilization time for selected program Sterilization temperature in chamber for selected Ster Temp: 134.0°C program Unwrapped Cycle: Cycle name pouches Cycle Num: 000082 Cycle number Version A.B.CC.DD = 1.0.00.00 A: Door Type: Single Manual = 1 B: Vacuum Type = 0 Version: 1.0.00.00...

  • Page 72: Printer Handling

    Printer Handling Maintenance Wipe off the soiling on the printer surface with a dry soft cloth with a weak neutral detergent. After that, wipe the printer with a dry cloth. Setting paper Printer model PLUS II Front view 1-Paper mouth 2-STATUS Led (blinking –...

  • Page 73: Treating The Thermal Papers

    Tear off the exceeding paper using the jagged edge (see Fig. 3/4). Fig. 3 Close the printer's cover door (1) by pulling it down, with the tip end of the paper emerging from the slot (2) (see Fig. 2). Treating the thermal papers: •...
  • Page 74 Power OFF the printer in any of the following cases: • The printer does not recover from an error. • Smoke, strange noise or smells erupt from the printer. • A piece of metal or any liquid touches the internal parts or slot of the printer.

  • Page 75: Preparation Before Sterilization

    Preparation before Sterilization The purpose of packaging and wrapping of items for sterilization is to provide an effective barrier against sources of potential contamination to maintain sterility and to permit aseptic removal of the contents of the pack. Packaging and wrapping materials should permit the removal of air from the pack, penetration of the sterilizing water vapor into the pack and removal of the sterilizing vapor.
  • Page 76 In case carbon steel instruments are placed on the stainless- steel tray, the tray should be lined with a towel or paper wrap before placing the instruments on the tray. There should be no direct contact between the carbon steel and the stainless-steel tray.

  • Page 77: Tubing

    Tubing • When placing tubing on the tray, make sure that both ends are open, without sharp bends or twists. Right Wrong Sterilization of Liquids Use only heat-proof glass, filled 2/3 full. Ensure that the glass container is covered but not sealed to prevent pressure build-up.

  • Page 78: Filling The Water Reservoir

    Filling the Water Reservoir Remove the water reservoir cover. Pour distilled water into the reservoir through the opening on top of the autoclave until it reaches the level of approximately 12 cm (0.5”0.75”) below the outlet of the return tube. The water quantity is 1617 liters (4.24.5 US gal). Use only water having the characteristics as per table in sec.

  • Page 79: Operating Instructions

    Operating Instructions Turning on the autoclave 10.1 • To start the system, turn on the main switch (1), located under the printer cover. The door is equipped with an electrical cylinder. This electrical cylinder performs the automatic opening and closing of the door. Opening the door –...

  • Page 80: Opening The Door - D Models (Automatic Door)

    Opening the door – D models (automatic door) 10.3 To open the door, follow the next steps: When the door is closed the screen below will be displayed: Press the Key in order to open the door The following screen will be displayed: If the door has opened successfully, the following screen will be displayed: Page 79...

  • Page 81: Safety

    Safety 10.4 Protective equipment and clothes and other safety instructions should be implemented in accordance with local and national regulations and/or rules! For proper sterilization - Do not overload the chamber. Only autoclavable products shall be used; please refer to the manufacturer instructions for sterilization of unknown materials or instruments.

  • Page 82: Closing The Door - Md Models (Mechanical Door)

    Closing the door – MD models (mechanical door) 10.7 Close the door. Move the door handle (1) from position "unlocked" (3) to position "locked" (2). The open door symbol is replaced by the message "System Ready". Closing and locking the door – D models (automatic 10.8 door) To close the door, follow the following steps:...
  • Page 83 While the door is locking the following screen will be displayed: When the door is properly locked, open door symbol will be replaced by the "System Ready" message as shown below: Page 82...

  • Page 84: Starting Cycle

    Starting cycle 10.9 Start the cycle by pressing the START/STOP key. The autoclave starts performing sequence of operations. The actual measured values of pressure and temperature are displayed continuously and printed every minute at STE stage, and every 5 minutes at the other stages. The phase in progress is displayed at the right side of the upper line as WATER, HEAT, STER., EXH., and DRY.

  • Page 85: Start Cycle By Clock Mode

    To release the door locking at the end of operation, press the UP key. The same applies at power up after fail. For MD models, rotate the handle counter clockwise to pull out the locking arms handle from the retaining brackets. Wear heat-resistant gloves or use the tray handle to remove the load from the autoclave.

  • Page 86: Service And Maintenance Instructions

    Service and Maintenance Instructions Preventive and Scheduled Maintenance 11.1 The maintenance operations described in this chapter must be fulfilled periodically to keep the device in good condition and to reduce the breakdown time to a minimum. The user maintenance personnel can easily execute these operations in accordance with further instructions.

  • Page 87: Draining The Reservoir

    Periodically On C models replace the air filter, every 6 months (to be performed by a technician). On Bio-Hazard models, replace the bio-hazard filter after 100 cycles. Check the door gasket every 12 months and replace it if required (see para.

  • Page 88: Cleaning Water Strainer

    Cleaning water strainer 11.3 Caution! Before proceeding, make sure that the electric cord is disconnected and there is no pressure in the autoclave. Open the strainer cover. Remove the strainer element. Rinse the strainer with water. Use a brush if necessary. Reinstall the strainer element.
  • Page 89 Description Strainer Strainer Strainer Gasket element Housing Page 88...

  • Page 90: Checking The Safety Valve

    Checking the Safety Valve 11.4 To prevent the safety valve from blockage, it is necessary to allow the steam pressure to escape through it (every month). The safety valve is in the rear top side of the autoclave. PED-approved type safety valve Operate the sterilization cycle according to the manual.
  • Page 91 Remove water reservoir cover. Operate the safety valve: Pull the valve’s handle and verify that steam escapes from the valve. Press the STOP key to pause operation, and exhaust steam from chamber. Wait until pressure goes down to zero, only then can the door be opened.

  • Page 92: Moving The Autoclave

    Moving the Autoclave 11.5 Disconnect the power supply cord. Disconnect the water and drain hoses. Disconnect the compressed air hoses (if applicable). Drain the water from the chamber. To avoid injuries, Moving the autoclave should be done by using a forklift.

  • Page 93: Troubleshooting

    Troubleshooting This troubleshooting chart enables the user to solve minor malfunctions, prior to contacting our service department. Only technical personnel having proper qualifications and holding technical documentation (including a technician manual) and adequate information are authorized to service the apparatus. Problem/ Message / Symbol Description Corrective Action...
  • Page 94 Problem/ Message / Symbol Description Corrective Action Error Message paramerter may need to be set. Turn the autoclave off This message is displayed if I/O "I/O Card and on again. If the card is faulty (both while cycle is Failed" problem persists, call for running or not).
  • Page 95 Problem/ Message / Symbol Description Corrective Action Error Message (Ending)" pressure ± 5kPa during the ending stage. This message is displayed if the "High system cannot reach preset Pressure Perform a new cycle. pressure within 10 minutes from (Exhaust)" the beginning of the exhaust stage. This message is displayed if the "High pressure in chamber exceeds...
  • Page 96 Problem/ Message / Symbol Description Corrective Action Error Message does not reach the atmospheric pressure and perform a pressure after 10 minutes. new cycle. The message is displayed if, when “Jacket is pressing Start/Stop, the Wait until the jacket cool” temperature of the jacket is below warms up.

  • Page 97: Baskets And Containers

    Model L x D x H (mm) Capacity L x D x H (mm) Capacity 5050 500 x 380 x 250 500 x 380 x 250 5075 715 x 380 x 250 715 x 380 x 250...

  • Page 98: Spare Parts List

    Spare Parts List Cat. No. Description 5050 5075 Strainer element, 400µ FIL175-0046 FIL175-0046 Cap for¼” strainer FIL175-0027 FIL175-0027 Teflon gasket 4mm GAS082-0008 GAS082-0008 Accessories List Cat. No. Description 5050 5075 Chamber Brite™ 1 box CLE096-0026 CLE096-0026 (10 packets) Printer (DPU30)
