EtherNet/IP Module
Installation Guide
The reset input is normally closed by default. If parameter 3-8 Remote Reset Logic is set to normally open, the reported state is
inverted (0 = closed, 1 = open).
For models MCD5-0053B and smaller, current reported via communications is 10 times greater than the actual value (shown on
the LCP).

8.3.2.3 Class 104 Objects (Read Only)

Class 104d (0x68) allows extended information to be read from the soft starter.
Object name
Major software version - User interface
Minor software version - User interface
Major software version - Motor control
Minor software version - Motor control
Major software version - Remote LCP (if installed)
Minor software version - Remote LCP (if installed)
Major software version - Expansion card (if installed)
Minor software version -. Expansion card (if installed)
Model rating
Control variant
Backplane variant
Actual motor current
Variant high byte
Customer

8.3.3 Supported Services for Vendor-specific Objects

This section describes the operational instructions to carry out acyclic services on class objects 100, 101, 102, 103, and 104.

8.3.3.1 Service Codes for Acyclic Operation

Table 7: Supported Services for Vendor-specific Objects
Service code Function
01d (0x01) Get attribute all
10d (0x10) Set attribute single
15d (0x0E) Get attribute single
28 | Danfoss A/S © 2022.10
N O T I C E
N O T I C E
Description
Only supported for class 0x01 identity object
Supported
Supported
Packet Structures
Class Instance
104 101
104 102
104 103
104 104
104 105
104 106
104 107
104 108
104 109
104 110
104 111
104 112
104 113
104 114
AN427641276310en-000101 / 175R1187
Attribute
100
100
100
100
100
100
100
100
100
100
100
100
100
100
