EtherNet/IP Module
Installation Guide
Bits Function
13 Reserved
14 Reserved
15 Temperature limit
8.2.3.2 Bytes 2–3: Reserved
Bits
0–15
8.2.3.3 Bytes 4–7: Motor Current
Bits Function Details
0–31 Motor current Average rms current across all 3 phases. Measured current is shown as a 32-bit value to 2 decimal places.
10d (0x0A) = 0.10 A
3450d (0xD7A) = 34.50 A
68930d (0x10D42) = 689.30 A
8.2.3.4 Bytes 8–9: Trip Code
Bits Function
0–15 Trip code
8.2.3.5 Bytes 10–11: Reserved
Bits
0–15

8.3 Explicit Messaging (Acyclic Operation)

This section provides information on objects, instances, attributes, and services for acyclic operation (explicit messaging).
All data is in little endian format.

8.3.1 Identity Object (Class 0x01)

Table 5: Supported Attributes for Identity Objects
Attribute
1
2
3
4
5
6
7
Danfoss A/S © 2022.10
Details
0 = Motor operating within thermal capacity (thermal model)
1 = Motor operating above thermal capacity (thermal model)
Function
Reserved
Details
See the chapter Trip Codes.
Function
Reserved
Function
Vendor
Device type
Product code
Revision: Major, minor
Status
Serial number
Product name
Packet Structures
Details
Details
Value
204d (0xCC)
12d (0x0C)
269d (0x10D)
EDS file version
Supported
Supported
Supported
AN427641276310en-000101 / 175R1187 | 25
