EtherNet/IP Module
Installation Guide

8.2.2.3 Command Examples

Byte Value
0 0b01000000 (64d, 0x40)
1 0b00000000 (00d, 0x00) or
0b00100000 (32d, 0x20)
0 0b10000000 (128d, 0x80)
0 0b11000000 (192d, 0xC0)
0 0bX0000000 (00d, 0x00)

8.2.3 Status Information (Assembly Instance 154d)

To retrieve status data from the soft starter, use assembly class 04d (0x04), assembly instance 154d (0x9A), attribute 03d (0x03).
8.2.3.1 Bytes 0–1: Starter State
Bits Function
0 Ready
1 Operating mode
2 Running
3 Trip
4 Jog forward
5 Jog reverse
6 Reserved
7 Warning
8 Ramping
9 Local/remote
10 Reserved
11 Reserved
12 Reserved
24 | Danfoss A/S © 2022.10
Description
Command: Start the soft starter.
Command: Select primary or secondary motor settings when starting.
Command: Reset the soft starter.
The reset only occurs when the previous reset bit is 0, otherwise the value of 1 is ig-
nored.
Command: Reset and start the soft starter.
Command: Stop the soft starter.
Details
0 = Not ready
1 = Ready to start
0 = Program mode
1 = Operating mode
0 = Not ready, ready to start, or tripped
1 = Starting, Running, Stopping, or Jogging
0 = Not tripped
1 = Tripped
1 = Jog forward
1 = Jog reverse
0 = No warning
1 = Warning
1 = Running (full voltage at the motor)
0 = Hand on
1 = Auto on
Packet Structures
AN427641276310en-000101 / 175R1187
