EtherNet/IP Module
Installation Guide

6 Scanner Configuration

6.1 EDS File

An EDS file is available from the website. The EDS file contains all required attributes of the EtherNet/IP module.
• For 175G9906, use EDS file SSEM10xxxx.eds.
• For 175G9907, use EDS file SSEM11xxxx.eds.
Once the EDS file has been loaded, the individual EtherNet/IP module must be defined.

6.2 Assembly Objects

Table 2: Supported Assembly Objects
Description
Output (Originator⇒Target)
Input (Target⇒Originator)
20 | Danfoss A/S © 2022.10
Class Instance
04d (0x04) 104d (0x68)
04d (0x04) 154d (0x9A)
Scanner Configuration
Type Maximum size
Integer 2 (4 bytes)
Integer 6 (12 bytes)
AN427641276310en-000101 / 175R1187
