- Page 1 FVM-1101 / FVM-1220 / FVM-1000 Web Smart Media Converter User Manual...
-
Page 2: Chapter 1 Overview
Chapter 1 Overview 1.1 Overview FVM-1101 / FVM-1220 / FVM-1000 is remote Managed 10/100 auto-negotiation Ethernet fiber media converter with OAM functions developed by our company. Remote devices can be managed by fiber-connected media converters/switches (which must support IEEE802.3ah standard). -
Page 3: Chapter 2 Technical Parameters
Chapter 2 Technical parameters 2.1 Basic parameter Structure Size 32mm×127mm×156mm (H×W×D） Optical Port SC/PC、ST/PC、FC/PC、SFP （0,45） Working temperature （℃） （-40,80） Storage temperature（℃） Power dissipation（W） Typical value:5W Relative humidity 5%~90% no condensing... -
Page 4: Chapter 3 Preparation Before Installing And Connection
Chapter 3 Preparation before Installing and Connection 3.1 Optical port connection FVM-1101 / FVM-1220 / FVM-1000 supports hot plug SFP port. When one pair of optical modules is connected, four requirements need to be fulfilled. Optical wavelengths must be the same, especially for single fiber optical ports, require transmit-receive optical wave with difference frequencies. - Page 5 3.4 Connection between Media converter and other devices with UTP cables Connecting the media converter and switch/router with cat UTP cables, the cables max length is to 100m. 1. Auto-negotiation of Ethernet port and MDIX/MDI function can be supported. RJ45 port Fiber media converter Other devices...
-
Page 6: Chapter 4 Led Status Of Device
Chapter 4 LED status of device 4.1 Sketch map of the front panel Sketch map of the front panel of FVM-1101 / FVM-1220 / FVM-1000 fiber media converter Indicator LED of FVM-1101 / FVM-1220 / FVM-1000 fiber media converters show the following... -
Page 7: Chapter 5 Web Interface
Chapter 5 WEB Interface 5.1 Login First, we input the device’s IP address 192.168.1.2 in the web browser, and then we could see the login page. We must input the correct the password to login the web, otherwise we could not access any web pages. The default Username is admin and the default password is 123456 and could be changed in the web. - Page 8 5.2 Network Information This menu is mainly for network interface and port status. It will show local system information, include MAC, IP, gateway, subnet mask address, software version number and device description. User could enable/disable remote device control ability. If enable remote device control ability, we could configure remote device and see remote device’s information.
- Page 9 will be provided by DHCP server. If the DHCP client is enabled, the IP address is provided by DHCP server, so user should make sure there is a DHCP server in the net before you enable this function. 5.5 Password Setting In this page, we could change the password.
- Page 10 packets will be dropped. Forward Pause Frame: If enable this function, The OAM Media Converter will forward pause frame and regard it as a normal packet. Management Packet High Priority: If enable this function, The OAM Media Converter will enable QOS. We enable four queues, and set queue 3 as strict priority.
- Page 11 “refresh” button, show the current MIB counters again. 5.9 SNMP Configuration This page could configure SNMP functions. SNMP Ability: Enable or Disable SNMP functions. Trap Mode: If enable, SNMP could send trap event to SNMP server. SNMP Trap IP Address: SNMP Server’s IP address, used for trap destination IP. 5.10 VLAN 5.10.1 VLAN Group If enable VLAN functions, user could set 16 VLAN entries.
- Page 12 5.10.2 VLAN per Port Setting In this page, we could set each port’s PVID and egress tag behavior. Egress Link Type: Replace Tag: The switch will remove VLAN tags from packets then add new tags to them. The inserted tag is the ingress port’s “Default tag”, which is indexed by port “Port based VLAN index”. This is a replacement processing for tagged packets and an insertion for untagged packets.
- Page 13 Out Layer VLAN VID: User defined Q-in-Q out layer VLAN tag VID VLAN Tag Priority Decision: Decide out layer VLAN Tag’s priority, use internal VLAN tag’s priority or 802.1p remarking decision priority. Q in Q direction: Select Q in Q direction, which port adds tag, and which port removes tag. 5.12 Remote Setting 5.12.1 TS1000 Functions 5.12.1.1 TS1000 Setting...
- Page 14 5.12.1.3 Remote Device Reset Through TS1000 function, we could let remote device do hardware reset. This function need both devices enable TS1000, local device in center mode and remote device in terminal mode. 5.12.1.4 Remote Port Information This page shows remote device port information.
- Page 15 5.12.1.5 Remote Port Setting In this page, user could enable/disable remote device’s UTP port, change remote device port’s speed & duplex and flow control ability. Fiber port should not be disabled. 5.13 802.3ah Functions 5.13.1 802.3ah Configuration This page could set 803.ah OAM function. User could enable/disable 802.3ah function and set its mode as passive or active mode.
- Page 16 5.13.2 Loopback Test This page could start 802.3ah loopback test. User could configure packet length and packet number. 5.13.3 802.3ah Status This page shows 802.3ah state machine information. 5.14 Tools 5.14.1 System Reboot Click the button “System Reboot” to reset this device.
- Page 17 5.14.2 Save and Restore Backup: Save local configuration to flash. Restore: Restore last saved configuration. Factory: User factory default setting. 5.14.3 Firmware Upgrade In this page, user could update the firmware by the web browser. User could click the browser button, select the new firmware image file, and then the new code image will be burned into the flash, and reset the device to use the new firmware.
-
Page 18: Chapter 6 Oam (Ieee802.3Ah) Function
FVM-1101 / FVM-1220 / FVM-1000 supports MIB variable response processed by switch chips, which is a subset of standard MIB. FVM-1101 / FVM-1220 / FVM-1000 responses only to requests of the initiative device, if the requesting object is MIB information that FVM-1101 / FVM-1220 / FVM-1000 doesn’t have, MIB variable response will return a null instruction.
