- Page 1 LevelOne User Manual VDS-0202 VDSL2 Ethernet Converter(BNC) V1.0.0-0803...
- Page 2 FCC Certifications This Equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
-
Page 3: Table Of Contents
Table of Content 1. INTRODUCTIONS ..................4 2. APPLICATION NOTES ................4 3. FEATURES....................5 4. PACKING CONTENTS................5 5. LED INDICATORS..................6 6. DIP SWITCHES SETTINGS ..............7 7. DATA RATES & DISTANCES..............9 8. TECHNICAL SUPPORT................. 10... -
Page 4: Introductions
CO for central side or RT for remote side by dip switch setting. The VDS-0202 conforms to the ITU-T G.993.1 and G.993.2 to meet VDSL/VDSL2 and SG15Q4 DMT for network requirements. A pair of VDS-0202 offers a cost effective solution for bandwidth-hungry applications such as Cable LAN-to-LAN connectivity, Video Streaming, FTTB, and MDU/MTU over single twisted pair telephone line. -
Page 5: Features
Features ITU-T G.993.1, G.993.2 VDSL/VDSL2 and SG15Q4 DMT Compliance 100/60Mbps DownSream/UpStream for distance up to 400 meters Supports VDSL2 connection up to 2000 meters Line Surge Protection BNC Connector for Cable interfaces + RJ45 x 2 for Ethernet LAN port Five LED Indicators 4 Dip Switches for Configuration Settings Trellis Coding support up to 1024 Discrete Multi-Tone (DMT) bins... -
Page 6: Led Indicators
LED Indicators On the front panel of VDS-0202, there are 5 LED indicators as the following VDS-0202 Front Panel VDS-0202 Rear Panel POWER Green On Indicates power is on and normal Green On Indicates Ethernet LAN1 port is in connection... -
Page 7: Dip Switches Settings
Dip Switches Settings Pin 1 Pin 2 Pin 3 Pin 4 VTU-C/R Mode Rate Limit VTU-C Interleaved 50/20 Mbps VTU-R Fast Full Rate Pin 1: VTU-C/R Switch VTU-C: The converter will act as at the Central Office (CO) side. VTU-R: The converter will act as at the Customer Premise Equipment (CPE) or Remote side. - Page 8 Pin 3: Rate limit control 50/20 Mbps: Line rate limited to 50/20 Mbps. Full Rate: Provides up to 100Mbps/60Mbps line rate in short line. Pin 4: Signal to Noise Ratio (SNR) 9dB: Higher SNR margin (9dB) will result in less error with more stable VDSL2 link. 6dB: Original and Normal channel noise protection with 6 dB SNR.
-
Page 9: Data Rates & Distances
Data Rates & Distances Performance in 5C2V Cable at 6dB with full rate Down Stream Data Rate (Mbps) Up Stream Data Rate (Mbps) Distance (feet) 1000 1250 1500 1750 2000 2500 3000 3500 4500... -
Page 10: Technical Support
Technical Support Thank you for selecting LevelOne products. LeveOne’s website contains the latest user documentation and soft-ware updates for LevelOne products. Please contact LevelOne Technical Support through our website. World Wide Web http://www.level1.com...
