7
Set the left margin.
Before inserting paper, move the left paper guide so that the print start
position you want aligns with the symbol [A printed on the margin
guide.
Left Paper Guide
Note: If you make a left margin setting in your application software,
8
To load a single sheet:
a
Place a single sheet against the left paper guide.
b
Move the right paper guide so that it aligns with the right edge of
the paper.
c
Push the sheet in until the Check light stops blinking.
54
Chapter 4: Selecting and Loading Paper
Printing begins at the [A symbol
The distance from the left paper guide to the [A
symbol determines the width of the left margin.
it is added to the left margin setting on the printer.
For example, if you set the left margin at 2.54 cm (1 in.) on the
printer, and also have the left margin set at 2.54 cm (1 in.) in
your application software, the printer begins printing 5.08 cm
(2 in.) from the left edge of the page.
Margin Guide
