Continuous Forms
Envelopes

Loading a Single Sheet or Envelope

Single sheets or multi-part forms can be loaded one at a time into the manual
feed.
Note: If you have installed the optional Auto Sheet Feeder or Tractor 2
Feeder, see "Auto Sheet Feeder" on page 76 or "Tractor 2 Feeder" on
page 85 for paper loading instructions.
Loading a Single Sheet or Envelope into the Manual
Feed
1
Turn the printer On.
2
Make sure the paper path is clear.
If continuous forms are currently loaded, see "Loading a Single Sheet
or Envelope With Continuous Forms Already Loaded" on page 57.
3
Make sure AutoGap is set to On or Single AutoGap. For help, see
"Setting AutoGap" on page 44.
4
Move the paper select lever up to the single sheets
52
Chapter 4: Selecting and Loading Paper
Single Multiple part
0.058-0.114 mm 0.512 mm (0.0202 in.)
(0.0023-0.0045 in.)
0.053 mm (0.021 in.)
position.
