Key Automation TURBO 400 Instructions And Warnings For Installation And Use page 7

4.5 - Limit switch fixing
The gate must feature mechanical stops for aperture and closure
that prevent the gate from derailing.
The position of the magnetic limit device must ensure that the limit
devices do not collide with the pinion.
Manually open the gate leaving, based on the weight of the gate, a
5 - CONTROL UNIT WIRING DIAGRAM
SPY
SPY
Selection of the 400 Vac power supply
Selection of the 230 Vac power supply
Selection of the power supply -10-
Line 230/400 Vac
Line 230/400 Vac
Line 230/400 Vac
Signal light or interior brake
Signal light or interior brake
24 Vac
24 Vac
Common
Common
Opening Limit Switch
Closing Limit Switch
Stop
Open -21-
Close
START
PEDESTRIAN
Mechanical edge NC
Photo-test FTS
Photo-test FTS
U -1-
V
-2-
-3-
W
T -4-
T -5-
-6-
-7-
-8-
-9-
Output for isolated contact of the 2nd channel
Output for isolated contact of the 2nd channel
-11-
-12-
-13-
-14-
-15-
-16-
-29-
-30-
COM
COM
N.C.
-17-
-18-
-19-
-20-
-22-
-23-
-24-
-25-
-26-
**
-27-
-28-
space between 30 a 50 mm. between the gate and the mechanical
stop.
Fix the limit device using the pins (fig.10) leaving a space between
the magnetic limit device and the reduction gear of max 10 mm
(fig.9) repeat the operation with the gate closed.
Three-phase motor (400V) or
single-phase motor ( 230V)
M
12 vac Output (up 1A)
12 vac Output (up 1A)
- Antenna
+ Antenna
Up 80W
*
N.O. N.O. N.O. N.O.
Fig. 10
12VAC
12VAC
OUT2
OUT2
GND
ANT
*
Connect this point to the FTS terminal
board for the photo-test otherwise con-
nect it to the 24V terminal board.
**
Connect to the 24V terminal board for test
CLOSE
Control board dispose of
command
2 buttons for opening and
closing of the door.
OPEN
See page no.4
command
EN
EN
Fig. 9
7 7
