Lexicon MV-5 Protocol Manual page 9

Lexicon
Selected
Input
Note: 0~1:2-Line OSD Off, 2,3:2-Line OSD 3 Sec, 4~6:2-Line OSD Off time(sec).
Note: Device cannot be in menu item to accept direct setting
0:FULL 1:HALF 2:OFF
Note: Device cannot be in menu item to accept direct setting
√
0:BYPASS 1:VIDEO CONV ON 2:FAROUDJA
Note: Device cannot be in menu item to accept direct setting
√
0(-6dB)~0x0C(+6dB)
Note: Device cannot be in menu item to accept direct setting
√
0(-6dB)~0x0C(+6dB)
Note: Bass/Treble are not global parameters so they apply only to input selected
Note: Device cannot be in menu item to accept direct setting
0(-8dB)~0x10(+8dB)
Note: Device cannot be in menu item to accept direct setting
(Tuner RV-5 only) FM Frequency Direct
0000 x10kHz (ex 87.50Mhz :0x222E,100.00Mhz:0x2710, 108.00Mhz:0x2A30)
Note: Device cannot be in menu item to accept direct setting
(Tuner RV-5 only) AM Frequency Direct
0000 x1khz (ex 520khz:0x0208, 1000khz:0x03e8, 1720khz:0x06B8)
Note: Device cannot be in menu item to accept direct setting
(Tuner RV-5 only) Preset Direct Access
0(Preset 1)~1E(Preset 30), 0 & 1 are same = 1
Note: Device cannot be in menu item to accept direct setting
Direct Setting Command
COMMAND
2Line OSD time setting
VFD Bright Setting
V-Process Setting
Main Volume Setting
0(-80dB) ~ 0x5A(+10dB)
Zone2 Volume Setting
0(-80dB) ~ 0x5A(+10dB)
Bass Level Setting
Treble Level Setting
EQ HF Shelf Level Setting
RV-5/MV-5 Serial Communications Protocol
Information Field (HEX )
1st 2nd
84 02
84 03
84 04
84 05
84 06
84 07
84 08
84 09
84 0A
84 0B
84 0C
3rd 4th
0~6 x
0~2 x
0~2 x
0~0x5A x
0~0x5A x
0~0x0C x
0~0x0C x
0~0x10 x
0x222E ~ 0x2A30
0x208 ~ 0x6B8
0~0x1E x
9
