Lexicon MV-5 Protocol Manual page 7

Lexicon
Selected
Input
COMMAND
iPOD |◀ ◀ (IPOD-)
iPOD ▶ ▶ | (IPOD+)
iPOD CCW (CLIK◀ )
iPOD CW (CLIK▶ )
iPOD MENU
iPOD SELECT
iPOD ▶ ||
PC |◀ ◀
PC ▶ ||
PC ▶ ▶ |
Z2:Volume + (cw)
Z2:Volume – (ccw)
Z2:OFF
Z2:MUTE (toggle)
Z2:HD select
Z2:DVD select
Z2:GAME select
Z2:SAT select
Z2:CABLE select
Z2:DVR select
Z2:CD select
Z2:DOCK select
Z2:PC select
Z2:TUNER select
Z2:AUX1 select
Z2:AUX2 select
Main Mute ON
RV-5/MV-5 Serial Communications Protocol
Information Field (HEX )
1st 2nd
82 0B
82 0B
82 0B
82 0B
82 0B
82 0B
82 0B
82 0B
82 0B
82 0B
82 0B
82 0B
82 0B
82 0B
82 0B
82 0B
82 0B
82 0B
82 0B
82 0B
82 0B
82 0B
82 0B
82 0B
82 0B
82 0B
83 0B
3rd 4th
4F B0
4E B1
0B F4
10 EF
81 7E
9D 62
89 76
CC 33
CE 31
CD 32
57 A8
56 A9
46 B9
55 AA
60 9F
61 9E
37 C8
64 9B
63 9C
65 9A
66 99
30 CF
4C B3
6A 95
6B 94
4D B2
01 x
