Lexicon MV-5 Protocol Manual page 10

Lexicon
Selected
Input
0(-15dB)~0x14(+5dB) CE,FR,SR....SUB2 : same
Note: Device cannot be in menu item to accept direct setting
Selected
Input
Direct Setting Command
COMMAND
FL Trim Level Setting
CEN Trim Level Setting
FR Trim Level Setting
SR Trim Level Setting
RR Trim Level Setting
RL Trim Level Setting
SL Trim Level Setting
SUB1 Trim Level Setting
SUB2 Trim Level Setting
Status Request Command
COMMAND
Display Status Request
Ram Status Request
Flag Status Request
Display Status Auto ON
Display Status Auto OFF
Ram Status Auto ON
Ram Status Auto OFF
Flag Status Auto ON
Flag Status Auto OFF
RV-5/MV-5 Serial Communications Protocol
Information Field (HEX )
1st 2nd
84 10
84 11
84 12
84 13
84 14
84 15
84 16
84 17
84 18
Information Field (HEX )
1st 2nd
83 0B
83 0B
83 0B
83 0B
83 0B
83 0B
83 0B
83 0B
83 0B
3rd 4th
0~0x14 x
0~0x14 x
0~0x14 x
0~0x14 x
0~0x14 x
0~0x14 x
0~0x14 x
0~0x14 x
0~0x14 x
3rd 4th
80 x
81 x
82 x
90 x
91 x
92 x
93 x
94 x
95 x
10
