Lexicon
3 Data Communication Format
Start Code
3.1 Start Code
PC -> AVR: "0xFF"
AVR -> PC: "0xFE"
3.2 Data Type
Remote Control through PC: 0x02
AVR Display Status: 0x03
AVR Ram Status: 0x04
AVR Flag Status: 0x05
3.3 Data Length
Information Field's Byte
Remote Control through PC: 4byte
AVR Status Display on PC: variable
3.4 Information Field
In hex code's Data
Data Type
RV-5/MV-5 Serial Communications Protocol
Data Length
Information Field
4
