Solinst Levelogger Series User Manual page 91

Rainlogger
The Rainlogger is designed for use with most standard tipping-bucket rain gauges. It records each tip time
from the tipping-bucket, and outputs the amount of rainfall per programmed time period (based on rainfall
calibration constant).
Note: Solinst recommends using the most recent Rainlogger firmware version with the latest Levelogger Software
version. See Section 2.3. If using a firmware version prior to version 2.000, the Rainlogger will function differently
(See previous Levelogger User Guide).
Rainlogger Technical Specifications
Battery Life:
Clock Accuracy (typical):
Operating Temperature:
Maximum # Readings:
Memory:
Communication:
Measurement:
Sampling Mode:
Size:
Weight:
Materials:
Levelogger Series User Guide - Appendix
10 years (logging 2 parameters/10 minutes)
± 1 minute/year
-20˚C to 80˚C
Up to 60,000 tip times
Slate mode
Optical infra-red: USB, RS-232, SDI-12
Records each tip by the tipping-bucket rain gauge and outputs
the amount of rainfall
Event Based, Future Start, Real TIme View
22 mm x 175 m (7/8" x 7")
135 grams (4.8 oz)
316L Stainless Steel, Delrin®, Viton®
V
