1.1.7 Barologger Edge

The Barologger Edge uses algorithms based on air pressure only. It measures and logs changes in atmospheric
pressure and temperature, which are then used to compensate water level readings recorded by a Levelogger.
Note: Solinst recommends using the most recent Barologger Edge firmware version with the latest Levelogger
Software version. See Section 2.3.
Level Sensor:
Accuracy:
Resolution:
Normalization:
Temp. Comp. Range:
Temperature Sensor:
Temp. Sensor Accuracy:
Temp. Sensor Resolution:
Battery Life:
Clock Accuracy (typical):
Operating Temperature:
Maximum # Readings:
Memory:
Communication Speed:
Com Interface:
Size:
Weight:
Corrosion Resistance:
Other Wetted Materials:
Sampling Modes:
Measurement Rates:
Barologger (M1.5)
Barologger Edge Technical Specifications
Piezoresistive Silicon with Hastelloy Sensor
± 0.05 kPa
0.002% FS
Automatic Temperature Compensation
-10ºC to 50ºC
Platinum Resistance Temperature Detector (RTD)
± 0.05ºC
0.003ºC
10 years (based on 1 reading/minute)
±1 minute/year (-20ºC to 80ºC)
-20ºC to 80ºC
40,000 sets of readings
Continuous or Slate mode
9600 bps, 38,400 bps with USB optical reader
Optical Infra-red: USB, RS-232, SDI-12
22 mm x 159 mm (7/8" x 6.25")
129 grams (4.5 oz.)
Titanium based PVD coated body and superior corrosion resistant
Hastelloy sensor
Delrin, Viton, 316L Stainless Steel
Linear, Event & User-Selectable Schedule with Repeat Mode,
Future Start, Future Stop, Real Time View
0.125 second to 99 hours
Model Full Scale (FS)
Air Only
Levelogger Series User Guide
Accuracy Resolution
±0.05 kPa 0.002% FS
