1.1.2 Barologger 5
The Barologger 5 uses algorithms based on air pressure only. It measures and logs changes in atmospheric
pressure and temperature, which are then used to compensate water level readings recorded by a Levelogger.
Note: Solinst recommends using the most recent Barologger 5 firmware version with the latest Levelogger Software
version. See Section 2.3.
Level Sensor:
Accuracy:
Resolution:
Normalization:
Temp. Comp. Range:
Temperature Sensor:
Temp. Sensor Accuracy:
Temp. Sensor Resolution:
Battery Life:
Clock Accuracy (typical):
Operating Temperature:
Maximum # Readings:
Memory:
Communication Speed:
Com Interface:
Size:
Weight:
Corrosion Resistance:
Sampling Modes:
Measurement Rates:
Barologger
Barologger 5 Technical Specifications
Piezoresistive Silicon with Hastelloy Sensor
± 0.05 kPa
0.002% FS
Automatic Temperature Compensation
-10ºC to 50ºC
Platinum Resistance Temperature Detector (RTD)
± 0.05ºC
0.003ºC
10 years (based on 1 reading/minute)
±1 minute/year (-20ºC to 80ºC)
-20ºC to 80ºC
150,000 sets of readings
Continuous or Slate mode
9600 bps, 57,600 bps with USB
Optical high-speed: USB, SDI-12
22 mm x 160 mm (7/8" x 6.3" )
166 grams (5.9 oz.)
Baked-on coating using polymerization technology (inside and out)
and superior corrosion resistant Hastelloy pressure sensor
Linear, Event & User-Selectable Schedule with Repeat Mode,
Future Start, Future Stop, Real Time View
0.125 second to 99 hours
Model
Full Scale (FS)
Air Only
Levelogger Series User Guide
Accuracy
Resolution
±0.05 kPa
0.002% FS
Page 7
