Solinst Levelogger Series User Manual page 10

1.1.5 Rainlogger 5
The Rainlogger 5 is designed for use with most standard tipping-bucket rain gauges. It records each tip time
from the tipping-bucket, and outputs the amount of rainfall per programmed time period based on rainfall
calibration constant shown on the tipping-bucket.
Note: Solinst recommends using the most recent Rainlogger 5 firmware version with the latest Levelogger Software
version. See Section 2.3.
Battery Life:
Clock Accuracy (typical):
Operating Temperature:
Maximum # Readings:
Memory:
Com Interface:
Communication Speed:
Measurement:
Sampling Mode:
Size:
Weight:
Materials:
Rainlogger 5 Technical Specifications
10 years (logging 2 parameters/10 minutes)
± 1 minute/year
-20˚C to 80˚C
Up to 100,000 tip times
Continuous or Slate mode
Optical high-speed: USB, SDI-12
9600 bps, 57,600 bps with USB
Records each tip by the tipping-bucket rain gauge and outputs
the amount of rainfall
Event Based, Future Start, Real TIme View
22 mm x 160 mm (7/8" x 6.3")
44 grams (1.6 oz)
ABS, Delrin, Viton
Tipping-Bucket
Connector Cable
Levelogger Series User Guide
