1.1.6 Levelogger Edge

The Levelogger Edge is an absolute (non-vented) datalogger, which measures groundwater and surface water
levels and temperature. Water levels are displayed as temperature compensated pressure readings, and can
be barometrically compensated with the aid of a Barologger.
Note: Solinst recommends using the most recent Levelogger Edge firmware version with the latest Levelogger
Software version. See Section 2.3.
Level Sensor:
Ranges:
Accuracy:
Resolution:
Normalization:
Temp. Comp. Range:
Temperature Sensor:
Temp. Sensor Accuracy:
Temp. Sensor Resolution:
Battery Life:
Clock Accuracy (typical):
Operating Temperature:
Maximum # Readings:
Memory:
Communication Speed:
Com Interface:
Size:
Weight:
Corrosion Resistance:
Other Wetted Materials:
Sampling Modes:
Measurement Rates:
Barometric Compensation:
M5
M10
M20
M30
M100
M200
Levelogger Edge Technical Specifications
Piezoresistive Silicon with Hastelloy Sensor
5, 10, 20, 30, 100, 200 m
± 0.05% FS
0.001% FS to 0.0006% FS
Automatic Temperature Compensation
0ºC to 50ºC
Platinum Resistance Temperature Detector (RTD)
± 0.05ºC
0.003ºC
10 years (based on 1 reading/minute)
± 1 minute/year (-20ºC to 80ºC)
-20ºC to 80ºC
40,000 sets of readings
Continuous or Slate mode
9600 bps, 38,400 bps with USB optical reader
Optical Infra-red: USB, RS-232, SDI-12
22 mm x 159 mm (7/8" x 6.25")
129 grams (4.5 oz.)
Titanium based PVD coated body and superior corrosion resistant
Hastelloy sensor
Delrin, Viton, 316L Stainless Steel
Linear, Event & User-Selectable Schedule with Repeat Mode,
Future Start, Future Stop, Real Time View
0.125 second to 99 hours
High accuracy, air-only, Barologger Edge
Models Full Scale
5 m (16.4 ft.)
10 m (32.8 ft.)
20 m (65.6 ft.)
30 m (98.4 ft.)
100 m (328.1 ft.)
200 m (656.2 ft.)
Levelogger Series User Guide
Accuracy Resolution
± 0.3 cm (0.010 ft.) 0.001% FS
± 0.5 cm (0.016 ft.) 0.0006% FS
± 1 cm (0.032 ft.) 0.0006% FS
± 1.5 cm (0.064 ft.) 0.0006% FS
± 5 cm (0.164 ft.) 0.0006% FS
± 10 cm (0.328 ft.) 0.0006% FS
