HECKLER AV Credenza Mini H891 Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
9/15/22, 9:54 AM
H891 Heckler AV Credenza
Mini
In the box
Tools needed
Install wall anchors
How to install a Snaptoggle wall anchors
Mount devices and cabling
Install credenza body
Install camera bracket for Logitech Rally Bar & Rally Bar Mini
Install camera bracket for Google Meet Series One Room Kit
Install camera bracket for PTZ cameras
Install front panel
In the box
A. 1 x main body (R502-1)
B. 1 x front panel (R509)
C. 1 x mounting bracket for Rally Bar & Rally Bar Mini (R502-2)
D. 2 x mounting bracket for Google Meet Series One Room Kit Audio Bar (R502-3)
E. 1 x wall-mounting template (K394)
F. 2 x mounting screw for camera brackets (F036)
https://heckler.notion.site/H891-Heckler-AV-Credenza-Mini-1f0d3ded48d24d04aaf6513838651a72
H891 Heckler AV Credenza Mini
1/15

Advertisement

loading
Need help?

Need help?

Do you have a question about the AV Credenza Mini H891 and is the answer not in the manual?

Questions and answers

Related Manuals for HECKLER AV Credenza Mini H891

Summary of Contents for HECKLER AV Credenza Mini H891

  • Page 1 9/15/22, 9:54 AM H891 Heckler AV Credenza Mini H891 Heckler AV Credenza Mini In the box Tools needed Install wall anchors How to install a Snaptoggle wall anchors Mount devices and cabling Install credenza body Install camera bracket for Logitech Rally Bar & Rally Bar Mini...
  • Page 2 R. 4 x drywall-mounting wall anchor (F037) S. 5-foot roll of hook & loop strap (F947) T. 5 x strapping buckle (F751) U. 2 x key (F033) Keys for all Heckler AV Credenza Mini’s are identical and interchangeable. https://heckler.notion.site/H891-Heckler-AV-Credenza-Mini-1f0d3ded48d24d04aaf6513838651a72 2/15...

  • Page 3: Tools Needed

    9/15/22, 9:54 AM H891 Heckler AV Credenza Mini Tools needed • Power drill • 1/2-inch drill bit • Philips screwdriver • Masking tape • Level • Tape measure • Stud finder Install wall anchors Tape the wall-mounting template(E) to the wall. Use a level.
  • Page 4 9/15/22, 9:54 AM H891 Heckler AV Credenza Mini We recommend mounting the credenza with its top surface at 36 inches above the finished floor (AFF). This aligns the credenza well with wall outlets at 18 inches AFF. Mark the locations of wall studs on the mounting template.
  • Page 5 9/15/22, 9:54 AM H891 Heckler AV Credenza Mini Mount devices and cabling You can mount devices and cabling before or after mounting the credenza to the wall Cut the provided hook & loop straps(S) to length as you needed for strapping components and cable management.
  • Page 6 9/15/22, 9:54 AM H891 Heckler AV Credenza Mini Fasten NUCs and other VESA-compatible devices to the VESA-compatible M4 clearance holes located between the large rectangular hole. M4 mounting hardware included(M and N). Install credenza body Hang the credenza on the top two anchor screws.
  • Page 7 9/15/22, 9:54 AM H891 Heckler AV Credenza Mini Fasten mounting screws(O) and washers(P) through the lower corners of the credenza body. Position a white nylon spacer(Q) between the body and the wall in each lower corner. Do not tighten the mounting screws.
  • Page 8 9/15/22, 9:54 AM H891 Heckler AV Credenza Mini Install camera bracket for Logitech Rally Bar & Rally Bar Mini Fasten the bracket(C) to Rally Bar with the 1/4-20 screws(G) and key(I) provided. https://heckler.notion.site/H891-Heckler-AV-Credenza-Mini-1f0d3ded48d24d04aaf6513838651a72 8/15...
  • Page 9 9/15/22, 9:54 AM H891 Heckler AV Credenza Mini Fasten mounting screws(F) to the bracket with key(I) provided. Do not tighten the screws at this step. This is a good opportunity to connect all cables to the Rally Bar and install its rear hatch.
  • Page 10 9/15/22, 9:54 AM H891 Heckler AV Credenza Mini Install camera bracket for Google Meet Series One Room Kit Fasten the pair of Google Meet mounting brackets(D) to the Google Meet Audio Bar with provided screws(H) and hex key(I). the upper corners of the main body. Position each bracket so the cork liner rests on the top surface of the credenza body.
  • Page 11 9/15/22, 9:54 AM H891 Heckler AV Credenza Mini Slide the bracket’s mounting screws into the horizontal keyhole slots on the back wall of the credenza. Tighten the screws with the provided hex key. https://heckler.notion.site/H891-Heckler-AV-Credenza-Mini-1f0d3ded48d24d04aaf6513838651a72 11/15...
  • Page 12 9/15/22, 9:54 AM H891 Heckler AV Credenza Mini This image couldn't be loaded. Learn more s3.us-west-2.amazonaws.com Install camera bracket for PTZ cameras Use the slot on the top surface of the credenza for mounting cameras with 1/4-20 mounting holes on their bottom surface.

  • Page 13: Install Front Panel

    9/15/22, 9:54 AM H891 Heckler AV Credenza Mini Place the camera on the top surface. Use the black spacer provided to lift the camera from the top surface a small distance. Fasten the camera to the credenza body with the provided wing nut(K).
  • Page 14 9/15/22, 9:54 AM H891 Heckler AV Credenza Mini This image couldn't be loaded. Learn more s3.us-west-2.amazonaws.com https://heckler.notion.site/H891-Heckler-AV-Credenza-Mini-1f0d3ded48d24d04aaf6513838651a72 14/15...
  • Page 15 H891 Heckler AV Credenza Mini Use the provided keys(U) to turn the cam lock on the underside of the credenza body. Keys for all Heckler AV Credenza Mini’s are identical and interchangeable. The locking feature is a low-security feature intended to reduce end-user tampering.
