HECKLER H608 Assembly & Installation

Ipad wall mount plus poe power secure wall enclosure for ipad 10.2-inch 7th generation

Advertisement

Quick Links

Heckler AV
®
iPad Wall Mount
plus PoE Power
Secure Wall Enclosure for iPad 10.2-inch 7th Generation
Assembly & Installation
Compatible with:
iPad 10.2-inch 7th Generation
Limited Warranty
Heckler Design warrants your product to be free from defect in material and
workmanship for a period of two years from the original date of purchase.
Electronic components are warranted to be free from defect for a period of one
year from the original date of purchase. If you discover a defect, please contact
service@hecklerdesign.com. Heckler Design will repair, at our discretion, using
new or refurbished components. If repair is not possible, Heckler Design will
replace the item.
H608
