Si001560EB
Step
5
Disconnect the 2
connectors from the
reactor.
6
Disconnect the
connector [S30].
7
Disconnect the
connector [S40].
Removal Procedure
Procedure
Reactor
Connector
(brown)
Connector
(orange)
(R22393)
[S30]: compressor
[S30]
(R22394)
[S40]: overload protector
[S40]
(R22395)
Electrical Box
Points
7
