Table 1. DD6400 system features (continued)
Feature
Cache SSDs Base (6% of 32 TBu)
Expanded (2.2% of 172 TBU)
16 GB NVRAM
HW Accelerator Quick Assist Technology (QAT) 8970
Internal SAS HBA330 12 Gbps SAS controller
External SAS Dual Port 12 Gbps SAS
SAS String Depth ES40
(max)
Host interface 2-port 25 GbE-SFP28
4-port 10 GbE-SFP+
4-port 10GBASE-T
4-port 16 Gb FC
Network Daughter 4-port 10 GbE-SFP+
Card option
4-port 10GBASE-T
(system will have
one of the two
options)

Product serial number tag (PSNT)

The PSNT provides the system serial number that is used as the initial administrator password for DD OS.
The system serial number is included in two places on the system:
● A small tag clipped to the back of the system, on the left side of the rear handle.
Figure 1. Rear tag
● A larger tag recessed into the front of the chassis on the right-hand side
Single Node
1 (Internal) 1.92 TB
2 (Internal) 1.92 TB
1
1
1
1
2
3 maximum
3 maximum
3 maximum
1 maximum
1
1
Introduction and Preparation 9
