  • Page 1 Panic Alarm Station User Manual...
  • Page 2 The Manual includes instructions for using and managing the Product. Pictures, charts, images and all other information hereinafter are for description and explanation only. The information contained in the Manual is subject to change, without notice, due to firmware updates or other reasons. Please find the latest version of this Manual at the Hikvision website (https://www.hikvision.com/).
  • Page 3 Panic Alarm Station User Manual Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC Compliance: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
  • Page 4 Panic Alarm Station User Manual the battery to your supplier or to a designated collection point. For more information see: www.recyclethis.info Industry Canada ICES-003 Compliance This device meets the CAN ICES-3 (A)/NMB-3(A) standards requirements.
  • Page 5 Panic Alarm Station User Manual Applicable Models This manual is applicable to the models listed in the following table. Model Product DS-PEA102S Panic Alarm Station DS-PEA102R DS-PEA102Y Symbol Conventions The symbols that may be found in this document are defined as follows.
  • Page 6 Never attempt to disassemble the device. Serial Port Accessing While accessing with serial port, enter 'debug' and then the system will print a string. Enter the string in the http://psh.hikvision.com.cn:8080/sso/home/page URL of to get the terminal control command. Insert the command to access to the device serial port.

  • Page 7: Table Of Contents

    Panic Alarm Station User Manual Table of Content Chapter 1 Overview ........................1 Description .......................... 1 Key Features ........................1 Chapter 2 Activation ........................2 Activate via SADP ......................... 2 Activate Device via Client Software ..................3 Chapter 3 Remote Settings ......................18 Device Management ......................
  • Page 8 Panic Alarm Station User Manual 3.6.6 Search for Log ......................42 3.6.7 Security Audit Log ..................... 43 3.6.8 Maintain the System ....................44 3.6.9 View Device Information ................... 45 3.6.10 View Device Information ..................46 Check Status ........................47 3.7.1 Check Zone Status ..................... 47 3.7.2 Check Relay Status ....................

  • Page 9: Chapter 1 Overview

    Panic Alarm Station User Manual Chapter 1 Overview Description DS-PEA102 series of panic alarm station supports two-way audio communication, and panic alarm, which realize alarm aid in emergency. The product is applied in school, hospital, metro, scenic area, prison, etc. Key Features ...

  • Page 10: Chapter 2 Activation

    Before You Start  Get the SADP software from the supplied disk or the official website http://www.hikvision.com/en/, and install the SADP according to the prompts.  The device and the PC that runs the SADP tool should be within the same subnet.

  • Page 11: Activate Device Via Client Software

    Before You Start  Get the iVMS-4200 client software from the supplied disk or the official website http://www.hikvision.com/en/. Install the software by following the prompts.  The device and the PC that runs the software should be in the same subnet.

  • Page 12: Chapter 3 Remote Settings

    Panic Alarm Station User Manual Chapter 3 Remote Settings In the client software, go to Device Management, click and select the device in the device list, and click to enter the Remote Configuration page. Note ● The device should be activated the first time it is used to log in and use properly. See Activation to activate the device.

  • Page 13: Network Configuration

    Panic Alarm Station User Manual management page. The following describes how to add devices through IP/Domain Name. For more information, see iVMS-4200 Client Software User Manual. Steps 1. On the Device page, click Add. 2. Select IP/Domain as the adding mode, edit the device information, including Name, Address, Port, User Name, and Password.
  • Page 14 Panic Alarm Station User Manual Network Basic Settings Page 2. Select the NIC type. 3. Set the network address. − Automatically obtain the network address Check Auto-obtain, the device automatically obtains the network address (IPv4 Address, Subnet Mask (IPv4), Default Gateway (IPv4)) through DHCP. −...
  • Page 15 Panic Alarm Station User Manual When the device accesses the network through the domain name, you need to configure the correct and available DNS server IP address. The device supports 2 DNS address. Click to enter the Remote Configuration page, go to Network → DNS, set the DNS server IP address and click Save to save the settings.
  • Page 16 Panic Alarm Station User Manual NAT Setting Page 2. Check Enable UPnP, and set Mapping Types as Manual or Auto. − Set Mapping Types as Auto The Ports are read-only, and the external ports are set by the router automatically. −...
  • Page 17 Panic Alarm Station User Manual After the SIP server address is set, the device actively registers to the SIP server, and devices under the same SIP server address can communicate with each other. Steps 1. Click to enter the Remote Configuration page, go to Network → SIP Settings. SIP Settings Page (Private Protocol &...
  • Page 18 Panic Alarm Station User Manual Hik-Connect Service Setting Page 2. Check Enable Hik-Connect Access and enter the verification code to enable Hik-Connect service. 3. Optional: If you want to edit Server Address, check Custom and enter the server address. Note The default server address is litedev.hik-connect.com.
  • Page 19 Panic Alarm Station User Manual Platform Access Configuration 2. Check Enable Platform Access to enable the Platform Access function. 3. Set the platform access parameters. Access Type Select the platform to be accessed. Server IP or Domain Name Enter the IP address or domain name of the platform. Access to Server Port Enter the port number of the platform.
  • Page 20 Panic Alarm Station User Manual Network Center Settings 2. Select a NIC. The device supports two wired networks and one wireless network. Each network supports uploading alarm information to one alarm center. 3. Check Enable Upload Center to enable the alarm center, and set the upload center parameters. Notify Surveillance Center Each NIC supports only one upload center, and the default is Net Center 1.

  • Page 21: Alarm Settings

    Panic Alarm Station User Manual Alarm Settings The device supports four alarm input zones and two default zones (emergency call help and consulting). You need to configure zone parameters. Steps The default zone has a default zone type, default audio file, and the default zone will automatically upload an alarm recovery report.

  • Page 22: Set Zone

    Panic Alarm Station User Manual Set Zone 4. Set zone parameters. Name Zone name. Detector Type The detector type of the zone. Zone Type Four zone type can be set for Non-default zones: Instant Zone, Fire Zone, 24-hour Non-voiced Zone, Shield Zone. Instant Zone In the armed state, as long as the detector connected to the zone is triggered, an alarm is generated immediately without delay.
  • Page 23 Panic Alarm Station User Manual Select an audio file for zone. Upload Alarm Recovery Report If check Upload Alarm Recovery Report, the report will be uploaded to the center when the alarm is restored. 5. Select the zone linkage. Linked Trigger After the zone is triggered, the selected alarm output is on.
  • Page 24 Panic Alarm Station User Manual Output Delay(s) The output delay time, can be set from 0 to 2000s. After the zone event is triggered, the relay will turn off the relay output after the output delay time is ended. 3. Click Save. 4.
  • Page 25 Panic Alarm Station User Manual Voice Prompt Configuration Page 2. Set the Center Busy File, Refuse Prompt, Voice Talk Ending Prompt, and Panic Alarm Prompt Sound. 3. Optional: Configure the mute program. 1) Check Enable to enable the mute program. 2) Click and drag the mouse on the time bar to draw the scheduled time period.

  • Page 26: Alarm Management

    Panic Alarm Station User Manual Alarm Management Open or close the relay via client software. Click to enter the Remote Configuration page, go to Alarm Management → Relay Relay Check the relays that need to be turned on/off. Click Enable/Locked to change the relay switch status.
  • Page 27 Panic Alarm Station User Manual Audio Input/Output 2. Set the audio input/output mode and volume. spkOut is the device's own audio input/output. 3. Click Save. Upload the custom audio files to SD card, and delete the audio file in the SD card. Before You Start Insert the SD card into the device.
  • Page 28 Panic Alarm Station User Manual Audio File Management 2. Upload the custom audio files. 1) Click View to select the audio file (can be selected in batch). 2) Check the audio file in the Upload File list and click Upload. Note ●...

  • Page 29: Video & Audio Settings

    Panic Alarm Station User Manual Video & Audio Settings Configure the image quality, resolution and other parameters of the camera. Click to enter the Remote Configuration page, click Image → Video & Audio. Video & Audio Select a camera, and set the video and audio parameters. Click Save to save the settings. ...
  • Page 30 Panic Alarm Station User Manual the maximum bitrate when the bitrate type is set as Variable. Video Quality You are able to choose different level of the video quality. The video quality is not optional by default when the bitrate type is Constant. Resolution According to the requirements for video clarity, the higher the resolution, the higher the bandwidth requirement for the network.
  • Page 31 Panic Alarm Station User Manual View Scale Select a camera from the drop-down box to configure the display parameters of the camera, including display position, display format and optional display content, you are able to add custom display information. Editing the display position Drag the blue box on the live view page to change the position of the display information, click Save, and then the position of the display information will be updated.
  • Page 32 Panic Alarm Station User Manual According to your requirement, check Display Name, Display Date, Display Week to display the selected display content. Click Save to save the settings.  Editing the camera name Editing the camera name in the Camera Name text box and click Save. ...

  • Page 33: System Settings

    Panic Alarm Station User Manual Intercom Audio Select the Audio Encoding Type as G711_U, PCM, ADPCM, AAC, or OPUS from the drop-down box. And click Save to save the settings. System Settings Click to enter the Remote Configuration page, go to Device Information → Time. Time You can set the time zone, NTP, DST on the Time page.
  • Page 34 Panic Alarm Station User Manual Click to enter the Remote Configuration page, go to System → General Parameters. General Parameters Set the device name and device No.. Click Save to save the settings. Enable/disable SSH service, which is used to provide security configuration for remote debugging. Click to enter the Remote Configuration page, go to System →...
  • Page 35 Panic Alarm Station User Manual Password Management IP Address The IP address of the terminal in which the locked user logs. Unlock The user's access lock status on the corresponding IP address. 2. Enable the access lock function and set the lock parameters. 1) Check Access Lock to enable the access lock function.
  • Page 36 Panic Alarm Station User Manual 2) Enter the new password and confirm it. 3) Click Save. User Search and view the alarm logs, exception logs, operation logs and event logs. Click to enter the Remote Configuration page, go to System → Log Query. You can set the search criteria and click Search, and the search result is in the list.

  • Page 37: Security Audit Log

    Panic Alarm Station User Manual Log Query You can click Backup and download the search result. Click to enter the Remote Configuration page, go to System → Security Audit Log. Security Audit Log...
  • Page 38 Panic Alarm Station User Manual 1. Check Enable Log Upload Server. 2. Set log server IP and server port. 3. Click … to upload the CA certificate. 4. Click Save. System management and remote upgrade. Click to enter the Remote Configuration page, go to System → System Maintenance. System Maintenance System Management You can reboot the device, restore default settings, restore all settings, and import/export...
  • Page 39 Panic Alarm Station User Manual  The configuration file contains the parameter information of the device.  It is required to enter the password created when exporting when import a file. Export Configuration File Export the configuration file from the device to the client software. ...

  • Page 40: View Device Information

    Panic Alarm Station User Manual Auto check Check the video and audio status automatically. Check Enable, set the detection time and click Save. Note The detection time can be selected as none, everyday or one day of the week. None Auto check function is not enabled.

  • Page 41: Check Status

    Panic Alarm Station User Manual Check Status Click to enter the Remote Configuration page, go to Status → Zone, you can view the status of zone alarm. Click to enter the Remote Configuration page, go to Status → Relay, you can view the relay status.

  • Page 42: Chapter 4 Web Client Settings

    Panic Alarm Station User Manual Chapter 4 Web Client Settings Live View You can see channel status, alarm log, zone, local relay, network status, device information, hardware status, etc. on live view page. Figure 4-1 Live View Page Configuration System Settings – Basic Information Click System →...

  • Page 43: Network

    Panic Alarm Station User Manual Enable DST. Configure Start Time, End Time and DST Bias. Click Save. System Settings – About Click System → System Settings → Time Settings. Click View Licenses to view open source software licenses. User Management Click System →...
  • Page 44 Panic Alarm Station User Manual you need to enter the port number in the login page. 3. Go to NAT page, enable UPnP to open the device port. 4. Select Port Mapping Mode as Auto or Manual. Auto You do not need to set port mapping on the router. You can open the port only by enabling UPnP.
  • Page 45 Panic Alarm Station User Manual Steps 1. Enable SIP. Enrollment Status Display the device enrollment status. If the device has been enrolled to the SIP server, it displays Enrolled. Otherwise it displays Not Enrolled. 2. Select IPv4 or Domain. 3. Set parameters. User Information You can enter IP, Server Port, User Name, Enrollment Password, etc.
  • Page 46 Panic Alarm Station User Manual Device ID The device ID number can only be set as a number and no more than 6 digits. The ID is the unique identification of the device, which facilitates the interaction between the panic alarm center station and front-end device.

  • Page 47: Image

    Panic Alarm Station User Manual Resolution Select according to the requirements of video definition. The higher the resolution, the higher the network bandwidth required. Bit Rate Type You can select Constant Bit Rate or Variable Bit Rate. The default is constant bit rate. If constant bit rate is selected, you need to select a fixed rate value;...
  • Page 48 Panic Alarm Station User Manual Audio Input The input type is micln by default. You can set the volume. Audio Output The output type is spkOut. You can set the volume. 3. Click Save. Figure 4-2 Audio Parameters Steps 1. Click Image → OSD Settings. 2.

  • Page 49: Custom

    Panic Alarm Station User Manual You can select the font size in the OSD size drop-down box. Alignment You can select Align Left, Custom, Align Right or International Mode in the alignment drop- down box. Change Display Content You can select the display content on the image, including the channel name, date and week, or change the channel name and add customized display content.
  • Page 50 Panic Alarm Station User Manual Type of zone detector. Zone Type Instant Under the arming status, as long as the detector connected to the zone is triggered, the alarm controller will immediately generate an alarm without delay. Fire The fire zone is a 24-hour alarm zone. When the fire zone is triggered, the external sounder will give a fire alarm sound.
  • Page 51 Panic Alarm Station User Manual Calling Settings Steps 1. Click Two-way Audio Settings → Calling Settings. 2. Configure parameters. Call Timeout Refers to the playing time of the call prompt tone. The range is 40 to 60 seconds. Call Extension Time When you press the call wait during calling the panic alarm center station, the extension time of the prompt tone based on the maximum ringing time is call extension time.
  • Page 52 Panic Alarm Station User Manual Click the drawn time period to adjust the start/end time in the pop-up window. Delete Time Period Click Erase, long press and drag the mouse on the drawn time period to erase. Delete All Time Period Click …...

  • Page 53: Maintenance And Security

    Panic Alarm Station User Manual to the default audio file. Maintenance and Security Reboot Click Maintenance and Security → Maintenance → Reboot to restart the device manually. Upgrade Steps Click Maintenance and Security → Maintenance → Upgrade. Click , select the upgrade file. Click Upgrade.
  • Page 54 Panic Alarm Station User Manual Audio&Video Self-Test Click Maintenance and Security → Maintenance → Audio&Video Self-Test, set manual test or auto test. Auto Test Audio and video self-test will be automatically performed according to the set detection time. Restore to Default Settings Click Test, the results will be shown in the result table.
  • Page 55 Panic Alarm Station User Manual Locking User Steps 1. Click Maintenance and Security → Security → Locking User. 2. Enable Locking, set parameters. Max. Failure Attempts The default setting is 7 times, and the setting range is 3 to 10. Locking Duration The default setting is 600 seconds, and the setting range is 10 to 3600.

  • Page 56: Chapter 5 Communication Matrix And Device Command

    Panic Alarm Station User Manual Chapter 5 Communication Matrix and Device Command Scan the QR code to get the communication matrix and device command...
  • Page 57 Panic Alarm Station User Manual UD24372B...
