Please read this instruction manual before using this product.
MultiVac 310 / 610 - MS
Aluminum Multi-Branch Manifold
MultiVac 300 / 600 - MS
MultiVac 300 / 600 - MB
MultiVac 301 / 601 - MB
Stainless Steel Multi-Branch Manifold
MultiVac 310 / 610 - MS - T
MultiVac 310 / 610 - MS - A
MultiVac 301 / 601 - MB - T
MultiVac 301 / 601 - MB - A
Vacuum Filtration System
Advertisement
Related Manuals for Rocker MultiVac 310-MS
Summary of Contents for Rocker MultiVac 310-MS
- Page 1 MultiVac 310 / 610 - MS Aluminum Multi-Branch Manifold MultiVac 300 / 600 - MS MultiVac 300 / 600 - MB MultiVac 301 / 601 - MB Stainless Steel Multi-Branch Manifold MultiVac 310 / 610 - MS - T MultiVac 310 / 610 - MS - A MultiVac 301 / 601 - MB - T MultiVac 301 / 601 - MB - A Vacuum Filtration System...
-
Page 2: Important Notice
(a) Ambient temperature: 5~ 40 °C (b) Relative humidity: 80% RH Max. (c) Power supply of Alligator 200: 100~240V, 50/60Hz Power supply of Rocker 400: 100~120V, 50/60Hz or 200~240V, 50/60Hz (d) Altitude: up to 2000 m (e) Pollution degree: II... - Page 3 I. Aluminum Multi-Branch Manifold MultiVac 310 - MS MultiVac 610 - MS Model Standard Package Includes: 3 Places Aluminum Manifold MultiVac 310 - MS with No. 8 Stopper Funnel Adaptor 6 Places Aluminum Manifold MultiVac 610 - MS with No. 8 Stopper Funnel Adaptor II.
- Page 4 Standard Package Includes: 3 Places Stainless Steel Manifold with Rocker SF Funnel Adaptor MultiVac 301 - MB Rocker, 100 ml SF Stainless Steel Funnel 6 Places Stainless Steel Manifold with Rocker SF Funnel Adaptor MultiVac 601 - MB Rocker, 100 ml SF Stainless Steel Funnel...
- Page 5 No. 8 Stopper Funnel Adaptor MultiVac 310 - MS - T MF 3, 300 ml Magnetic Filter Holder with Lid Kit Aluminum Rocker 400, Oil Free Vacuum Pump Vacuum Filtration System 4000 ml PP Vacuum Bottle with drain Silicone Tube 6 Places Aluminum Manifold with No.
- Page 6 MultiVac 601 - MB - T Model Standard Package Includes: 3 Places Stainless Steel Manifold with Rocker SF Funnel Adaptor Rocker, 100 ml SF Stainless Steel Funnel MultiVac 301 - MB - T Rocker 400, Oil Free Vacuum Pump Stainless Steel Dragon 100, Torch Burner...
- Page 7 IV. Vacuum Filtration System (with Alligator 200 Liquid Pump) MultiVac 310 - MS - A MultiVac 610 - MS - A Model Standard Package Includes: 3 Places Aluminum Manifold with No. 8 Stopper Funnel Adaptor MultiVac 310 - MS - A MF 3, 300 ml Magnetic Filter Holder with Lid Kit Aluminum Alligator 200, Diaphragm Liquid Pump...
- Page 8 MultiVac 601 - MB - A Model Standard Package Includes: 3 Places Stainless Steel Manifold with Rocker SF Funnel Adaptor Rocker, 100 ml SF Stainless Steel Funnel MultiVac 301 - MB - A Alligator 200, Diaphragm Liquid Pump Stainless Steel Dragon 100, Torch Burner Vacuum Filtration System Pall, MCE Membrane, 47 mm, 0.45 μm, 200/PK...
- Page 9 Installation and Operation A. Attention Both Aluminum and Stainless Steel Multi-Branch Manifold MultiVac manifold can be connected with vacuum pump or liquid pump. When connect with a vacuum pump, it is always recommended to install a vacuum bottle between the manifold and vacuum pump to prevent liquid from flowing into the vacuum pump.
- Page 10 Manifold Preparation and Installation Make sure all valves are off before use, rotate the valves counterclockwise to vertical position for filtration. Stainless Steel Multi-Branch Manifold can easily change the funnel adaptor to fit desired funnel. Loosen the fixing screw with L-Type hex key (2 mm) to change the funnel adaptor and tighten the screw to prevent new funnel adaptor from rotation.
- Page 11 Compatible with various kinds of filter holders with No. 8 silicone stopper • Stainless Steel Multi-Branch Manifold only (2) Rocker SF Funnel Adaptor Fitting to Rocker SF 100 / 300 / 500 ml funnel, available for fast flame sterilization, ® and Pall , Sentino 4870 (100 ml), 4871 (250 ml) plastic funnel.
- Page 12 Vacuum Filtration System Installation and Operation I. Vacuum Filtration System (with Rocker 400 Vacuum Pump) Connect the installed manifold, vacuum bottle and Rocker 400 vacuum pump with 2 silicone tubes as shown below. Install the membrane in filter holder or funnel as B-3 step.
- Page 13 II. Vacuum Filtration System (with Alligator 200 Diaphragm Liquid Pump) Connect the installed manifold and inlet (IN) of Alligator 200 liquid pump together with silicone tube as shown below. Connect the long silicone tube to outlet (OUT) of Alligator 200 liquid pump and put another side of silicone tube into sink or container to drain or collect the waste liquid.
-
Page 14: Maintenance
Maintenance Please suck in pure water to clean the tubing after every use and keep pumping air for at least 3 min to drain out the residual liquid. Pump is not autoclavable, please clean the surface with pure water or 75% ethanol. -
Page 15: Troubleshooting
Troubleshooting Problem Reason and Solution Instrument Loose plug Reconnect plug to power supply. fails to start Switch is broken Contact distributor for assistance. Outlet is blocked Clean or stretch the outlet tube. Funnel adaptor O-ring is broken Replace the O-ring Poor vacuum ... -
Page 16: Ordering Information
SS316 Adaptor for Sartorius 16A07 Disposable Plastic Funnel 190100-75 SS316 Adaptor for Pall 4870, 4871 Disposable Plastic Funnel 180100-01/03/05 Rocker SF Stainless Steel Funnel 100 ml / 300 ml / 500ml 200300-01 MF 3, 300 ml Magnetic Filter Holder 200500-01...
