- Page 1 Instruction Manual Rocker 300 / 300DC / 400 / 410 Rocker 800 / 801 / 810 / 811 Oil Free Vacuum Pump Please read this instruction manual before using this product.
-
Page 2: Important Notice
11. If the supply cord is damaged, Please contact the manufacturer or your service local dealer for replacement to avoid hazard. Unpacking When unpacking, notice if the pump is in good condition. If not, please contact the distributor or contact us by e-mail: export@rocker.com.tw immediately for assistance. - Page 3 Rocker 300 Main Part Diagram Position Designation On/Off Switch Muffler (Air Outlet) Air Inlet Vacuum Gauge Prote Filter Cartridge Moisture Trap Drain Valve (Regulator)
- Page 4 Rocker 300DC Main Part Diagram Position Designation On/Off Switch Muffler (Air Outlet) Air Inlet Vacuum Gauge Prote Filter Cartridge Moisture Trap Drain Valve (Regulator) Power Cord...
- Page 5 Rocker 400 / 410 Main Part Diagram Position Designation On/Off Switch Muffler (Air Outlet) Air Inlet Vacuum Gauge Prote Filter Cartridge Moisture Trap Drain Valve (Regulator)
- Page 6 Rocker 800 Main Part Diagram Position Designation Muffler (Air Outlet) Vacuum Gauge Vacuum Regulator Air Inlet On/Off Switch...
- Page 7 Rocker 801 Main Part Diagram Position Designation On/Off Switch Muffler (Air Outlet) Air Inlet Vacuum Gauge Filter Cartridge Moisture Trap Vacuum Regulator...
- Page 8 Rocker 810 Main Part Diagram Position Designation Muffler (Air Outlet) Vacuum Gauge Vacuum Regulator Air Inlet On/Off Switch...
- Page 9 Rocker 811 Main Part Diagram Position Designation On/Off Switch Muffler (Air Outlet) Air Inlet Vacuum Gauge Filter Cartridge Moisture Trap Vacuum Regulator...
-
Page 10: Operation
Operation Operating procedure 1. Press on/off switch to activate the pump after making sure all tubing are well connected. 2. To setup vacuum by adjusting the regulator * Warning: When pump is used for aqueous solution ltration, please ensure the liquid level of ask not exceed safety level. -
Page 11: Ordering Information
Rocker 801 Vacuum pump, AC110V,60Hz (AC220V,50Hz) 167810-11(22) Rocker 810 Vacuum pump, AC110V,60Hz (AC220V,50Hz) 167811-11(22) Rocker 811 Vacuum pump, AC110V,60Hz (AC220V,50Hz) 167301-06 Moisture trap / Vacuum regulator for Rocker 300/400/410 167301-07 Prote filter cartridge for Rocker 300/400/410 167300-42 Muffler (Air outlet) for Rocker 300/400/410... - Page 12 Rocker Scienti c Co., Ltd. Tel: +886-2-26033311 Fax: +886-2-26036622 E-mail:export@rocker.com.tw https://www.rocker.com.tw...
